posted 05-21-2008 06:09 PM

NASA's Kepler mission to find Earth-size planets

Kepler is a spaceborne telescope designed to search the nearby region of our galaxy for Earth-size planets orbiting in the habitable zone of stars like our sun. The habitable zone is the region around a star where temperatures permit water to be liquid on a planet's surface.

Liquid water is considered essential for the existence of life as we know it. The vast majority of the approximately 300 planets known to orbit other stars are much larger than Earth, and none is believed to be habitable.

The challenge for Kepler is to look at a large number of stars in order to statistically estimate the total number of Earth-size planets orbiting sun-like stars in the habitable zone. Kepler will survey more than 100,000 stars in our galaxy.

posted 02-19-2009 01:21 AM

At the Hazardous Processing Facility at Astrotech in Titusville, Fla., workers position the Kepler spacecraft onto a Delta II third stage.

Kepler is designed to survey more than 100,000 stars in our galaxy to determine the number of sun-like stars that have Earth-size and larger planets, including those that lie in a star's "habitable zone," a region where liquid water, and perhaps life, could exist. If these Earth-size worlds do exist around stars like our sun, Kepler is expected to be the first to find them and the first to measure how common they are.

The liftoff of Kepler aboard a Delta II rocket is currently targeted for 10:48 p.m. EST March 5 from Space Launch Complex 17 on Cape Canaveral Air Force Station.

posted 03-02-2009 01:27 AM

NASA's Kepler Telescope to Launch Aboard Delta II Rocket

Launch of NASA's Kepler telescope is targeted for no earlier than Friday, March 6, from Pad 17-B at Cape Canaveral Air Force Station in Florida. There are two launch windows, from 10:49 - 10:52 p.m. and 11:13 - 11:16 p.m. EST.

Kepler is a spaceborne telescope designed to search the nearby region of our galaxy for Earth-size planets orbiting in the habitable zone of stars like our sun. The habitable zone is the region around a star where temperatures permit water to be liquid on a planet's surface.

Liquid water is considered essential for the existence of life as we know it. The vast majority of the approximately 300 planets known to orbit other stars are much larger than Earth, and none is believed to be habitable. The challenge for Kepler is to look at a large number of stars in order to statistically estimate the total number of Earth-size planets orbiting sun-like stars in the habitable zone. Kepler will survey more than 100,000 stars in our galaxy.

Engineers are reviewing all common hardware between the Delta II rocket carrying the Kepler telescope and the Taurus XL launch vehicle. On Tuesday, a Taurus carrying NASA's Orbiting Carbon Observatory failed to reach orbit. Managers want to confirm there will not be similar issues with Kepler's Delta II.

Kepler's original March 5 target launch date was moved one day later to accommodate the additional time for analysis. The March 6 target date still must be confirmed by the U.S Air Force, which manages the eastern launch range. Kepler's Flight Readiness Review is on Monday, March 2.

NASA's Launch Services Program at NASA's Kennedy Space Center, Fla., is responsible for the launch of Kepler aboard a Delta II 7925-10L rocket. United Launch Alliance is conducting the launch for NASA. NASA's Ames Research Center, Moffett Field, Calif., is the home organization of the principal science investigator and is responsible for the ground system development, mission operations and science data analysis. NASA's Jet Propulsion Laboratory, Pasadena, Calif., is responsible for the spacecraft and the Kepler mission development. Ball Aerospace & Technologies Corporation of Boulder, Colo., is responsible for developing and building the Kepler spacecraft and supporting mission operations.

NASA Television Coverage

NASA Television coverage of the Kepler prelaunch press conference and of the launch will be carried on the NASA TV Public Channel (Channel 101).

NASA Television coverage of the Kepler prelaunch news conference and mission science briefing at Kennedy will begin at 1 p.m. on Thursday, March 5.

NASA Web Prelaunch and Launch Coverage

Kepler's prelaunch webcast, featuring Kepler's Deputy Principal Investigator Dr. David Koch and Kennedy Mission Manager Armando Piloto, will be streamed on the Web and broadcast on NASA TV on Thursday, March 5, at 11:30 a.m.

Live countdown coverage through NASA's launch blog begins at 9 p.m. Friday, March 6. Coverage features real-time updates as countdown milestones occur as well as streaming video clips highlighting launch preparations and liftoff.

posted 03-05-2009 03:30 PM

NASA's Kepler Mission Set For Launch

NASA's Kepler mission to seek other Earth-like planets is undergoing final preparations for liftoff Friday, March 6, from Pad 17-B at Cape Canaveral Air Force Station in Florida. The spacecraft launch aboard a Delta II rocket has two windows of opportunity Friday, from 10:49 to 10:52 p.m. and 11:13 to 11:16 p.m. EST.

Kepler is designed to find the first Earth-size planets orbiting stars in habitable zones -- regions where water could pool on the surface of the planets. Liquid water is believed to be essential for the formation of life.

"This mission attempts to answer a question that is as old as time itself -- are other planets like ours out there?" said Ed Weiler, associate administrator for NASA's Science Mission Directorate at NASA Headquarters in Washington. "It's not just a science question -- it's a basic human question."

After the clock ticks down to liftoff, the Delta II's first-stage main engine and six strap-on solid rocket boosters will ignite. Three remaining boosters will ignite 65.5 seconds later, and the first-stage main engine will continue to burn for 4.5 minutes. The second stage will then ignite, carrying Kepler into a circular orbit 115 miles above Earth less than 10 minutes after launch. After coasting for 43 minutes, the second-stage engine will fire again, followed by second-stage shutdown and separation. The third stage will then burn for five minutes.

Sixty-two minutes after launch Kepler will have separated entirely from its rocket and will be in its final Earth-trailing orbit around the sun, an orbit similar to that of NASA's Spitzer Space Telescope. "We are very excited to see this magnificent spacecraft come to life when it reaches space," said James Fanson, Kepler project manager at NASA's Jet Propulsion Laboratory, Pasadena, Calif.

After a commissioning period lasting about two months, Kepler will begin its job of staring at more than 100,000 stars for three-and-one-half years, looking for planets. Its isolated perch behind Earth will give the telescope an unobstructed view of a single, very large patch of sky near the Cygnus and Lyra constellations.

"We will monitor a wide range of stars; from small cool ones, where planets must circle closely to stay warm, to stars bigger and hotter than the sun, where planets must stay well clear to avoid being roasted," said William Borucki, science principal investigator for the mission at NASA's Ames Research Center at Moffett Field, Calif. Borucki has been working on the mission for 17 years. "Everything about the mission is optimized to find Earth-size planets with the potential for life, to help us answer the question -- are Earths bountiful or is our planet unique?"

Kepler will find planets by looking for periodic dips in starlight. Planets that happen to pass directly in front of their stars from Earth's point of view cause the stars to dim by almost imperceptible amounts. Kepler's powerful camera, the largest ever flown in space, can see the faintest of these "winks."

"Trying to detect Jupiter-size planets crossing in front of their stars is like trying to measure the effect of a mosquito flying by a car's headlight," said Fanson. "Finding Earth-sized planets is like trying to detect a very tiny flea in that same headlight."

If the mission does find Earth-sized planets in the habitable zones of stars, it should find them first around stars that are smaller than our sun. This is because the habitable zone is closer for small stars; planets circling in this region would take less time to complete one lap and, theoretically, less time for Kepler to find them and for other ground-telescopes to confirm their existence. Any Earth-size planets orbiting in the habitable zones of stars like our sun -- the true Earth analogs -- would take at least three years to be confirmed.

Kepler is a NASA Discovery mission. Ames is the home organization of the science principal investigator and is responsible for the ground system development, mission operations and science data analysis. NASA's Jet Propulsion Laboratory in Pasadena, Calif., manages the Kepler mission development. Ball Aerospace & Technologies Corp. of Boulder, Colo., is responsible for developing the Kepler flight system and supporting mission operations. NASA's Launch Services Program at NASA's Kennedy Space Center, Fla., manages the launch service including payload integration and certifying the Delta II launch vehicle for NASA's use.

posted 03-06-2009 10:44 PM

NASA's Kepler Mission Rockets to Space in Search of Other Earths

NASA's Kepler mission successfully launched into space from Cape Canaveral Air Force Station, Fla., aboard a United Launch Alliance Delta II at 10:49 p.m. EST, Friday. Kepler is designed to find the first Earth-size planets orbiting stars at distances where water could pool on the planet's surface. Liquid water is believed to be essential for the formation of life.

"It was a stunning launch," said Kepler Project Manager James Fanson of NASA's Jet Propulsion Laboratory in Pasadena, Calif. "Our team is thrilled to be a part of something so meaningful to the human race -- Kepler will help us understand if our Earth is unique or if others like it are out there."

Engineers acquired a signal from Kepler at 12:11 a.m. Saturday, after it separated from its spent third-stage rocket and entered its final sun-centered orbit, trailing 950 miles behind Earth. The spacecraft is generating its own power from its solar panels.

"Kepler now has the perfect place to watch more than 100,000 stars for signs of planets," said William Borucki, the mission's science principal investigator at NASA's Ames Research Center at Moffett Field, Calif. Borucki has worked on the mission for 17 years. "Everyone is very excited as our dream becomes a reality. We are on the verge of learning if other Earths are ubiquitous in the galaxy."

Engineers have begun to check Kepler to ensure it is working properly, a process called "commissioning" that will take about 60 days. In about a month or less, NASA will send up commands for Kepler to eject its dust cover and make its first measurements. After another month of calibrating Kepler's single instrument, a wide-field charge-couple device camera, the telescope will begin to search for planets.

The first planets to roll out on the Kepler "assembly line" are expected to be the portly "hot Jupiters" -- gas giants that circle close and fast around their stars. NASA's Hubble and Spitzer space telescopes will be able to follow up with these planets and learn more about their atmospheres. Neptune-size planets will most likely be found next, followed by rocky ones as small as Earth. The true Earth analogs -- Earth-sized planets orbiting stars like our sun at distances where surface water, and possibly life, could exist -- would take at least three years to discover and confirm. Ground-based telescopes also will contribute to the mission by verifying some of the finds.

In the end, Kepler will give us our first look at the frequency of Earth-size planets in our Milky Way galaxy, as well as the frequency of Earth-size planets that could theoretically be habitable.

"Even if we find no planets like Earth, that by itself would be profound. It would indicate that we are probably alone in the galaxy," said Borucki.

As the mission progresses, Kepler will drift farther and farther behind Earth in its orbit around the sun. NASA's Spitzer Space Telescope, which was launched into the same orbit more than five years ago, is now more than 62 million miles behind Earth.

Kepler is a NASA Discovery mission. Ames is the home organization of the science principal investigator and is responsible for the ground system development, mission operations and science data analysis. JPL manages the Kepler mission development. Ball Aerospace & Technologies Corp. of Boulder, Colo., is responsible for developing the Kepler flight system and supporting mission operations. NASA's Launch Services Program at NASA's Kennedy Space Center, Fla., managed the launch service including payload integration and certifying the Delta II launch vehicle for NASA's use.

posted 04-08-2009 09:53 AM

Dust Cover Jettisoned From NASA's Kepler Telescope

Engineers have successfully ejected the dust cover from NASA's Kepler telescope, a spaceborne mission soon to begin searching for worlds like Earth.

"The cover released and flew away exactly as we designed it to do," said Kepler Project Manager James Fanson of NASA's Jet Propulsion Laboratory, Pasadena, Calif. "This is a critical step toward answering a question that has come down to us across 100 generations of human history -- are there other planets like Earth, or are we alone in the galaxy?"

Kepler, which launched on March 6 from Cape Canaveral, Fla., will spend three-and-a-half years staring at more than 100,000 stars in our Milky Way galaxy for signs of Earth-size planets. Some of the planets are expected to orbit in a star's "habitable zone," a warm region where water could pool on the surface. The mission's science instrument, called a photometer, contains the largest camera ever flown in space -- its 42 charge-coupled devices (CCDs) will detect slight dips in starlight, which occur when planets passing in front of their stars partially block the light from Kepler's view.

The telescope's oval-shaped dust cover, measuring 1.7 meters by 1.3 meters (67 inches by 52 inches), protected the photometer from contamination before and after launch. The dust cover also blocked stray light from entering the telescope during launch -- light that could have damaged its sensitive detectors. In addition, the cover was important for calibrating the photometer. Images taken in the dark helped characterize noise coming from the instrument's electronics, and this noise will later be removed from the actual science data.

"Now the photometer can see the stars and will soon start the task of detecting the planets," said Kepler's Science Principal Investigator William Borucki at NASA's Ames Research Center, Moffett Field, Calif. "We have thoroughly measured the background noise so that our photometer can detect minute changes in a star's brightness caused by planets."

At 7:13 p.m. PDT on April 7, engineers at Kepler's mission operations center at the Laboratory for Atmospheric and Space Physics, Boulder, Colo., sent commands to pass an electrical current through a "burn wire" to break the wire and release a latch holding the cover closed. The spring-loaded cover swung open on a fly-away hinge, before drifting away from the spacecraft. The cover is now in its own orbit around the sun, similar to Kepler's sun-centric orbit. See an animation of the event.

With the cover off, starlight is entering the photometer and being imaged onto its focal plane. Engineers will continue calibrating the instrument using images of stars for another several weeks, after which science observations will begin.

Kepler is a NASA Discovery mission. NASA's Ames Research Center Ames is the home organization of the science principal investigator, and is responsible for the ground system development, mission operations and science data analysis. NASA's Jet Propulsion Laboratory, Pasadena, Calif., manages the Kepler mission development. Ball Aerospace & Technologies Corp., Boulder, Colo., is responsible for developing the Kepler flight system and supporting mission operations.

posted 04-16-2009 02:40 PM

NASA's Kepler Captures First Views of Planet-Hunting Territory

NASA's Kepler mission has taken its first images of the star-rich sky where it will soon begin hunting for planets like Earth.

The new "first light" images show the mission's target patch of sky, a vast starry field in the Cygnus-Lyra region of our Milky Way galaxy. One image shows millions of stars in Kepler's full field of view, while two others zoom in on portions of the larger region.

"Kepler's first glimpse of the sky is awe-inspiring," said Lia LaPiana, Kepler's program executive at NASA Headquarters in Washington. "To be able to see millions of stars in a single snapshot is simply breathtaking."

One new image from Kepler shows its entire field of view -- a 100-square-degree portion of the sky, equivalent to two side-by-side dips of the Big Dipper. The regions contain an estimated 14 millions stars, more than 100,000 of which were selected as ideal candidates for planet hunting.

Two other views focus on just one-thousandth of the full field of view. In one image, a cluster of stars located about 13,000 light-years from Earth, called NGC 6791, can be seen in the lower left corner. The other image zooms in on a region containing a star, called Tres-2, with a known Jupiter-like planet orbiting every 2.5 days.

"It's thrilling to see this treasure trove of stars," said William Borucki, science principal investigator for Kepler at NASA's Ames Research Center at Moffett Field, Calif. "We expect to find hundreds of planets circling those stars, and for the first time, we can look for Earth-size planets in the habitable zones around other stars like the sun."

Kepler will spend the next three-and-a-half years searching more than 100,000 pre-selected stars for signs of planets. It is expected to find a variety of worlds, from large, gaseous ones, to rocky ones as small as Earth. The mission is the first with the ability to find planets like ours -- small, rocky planets orbiting sun-like stars in the habitable zone, where temperatures are right for possible lakes and oceans of water.

To find the planets, Kepler will stare at one large expanse of sky for the duration of its lifetime, looking for periodic dips in starlight that occur as planets circle in front of their stars and partially block the light. Its 95-megapixel camera, the largest ever launched into space, can detect tiny changes in a star's brightness of only 20 parts per million. Images from the camera are intentionally blurred to minimize the number of bright stars that saturate the detectors. While some of the slightly saturated stars are candidates for planet searches, heavily saturated stars are not.

"Everything about Kepler has been optimized to find Earth-size planets," said James Fanson, Kepler's project manager at NASA's Jet Propulsion Laboratory in Pasadena, Calif. "Our images are road maps that will allow us, in a few years, to point to a star and say a world like ours is there."

Scientists and engineers will spend the next few weeks calibrating Kepler's science instrument, the photometer, and adjusting the telescope's alignment to achieve the best focus. Once these steps are complete, the planet hunt will begin.

"We've spent years designing this mission, so actually being able to see through its eyes is tremendously exciting," said Eric Bachtell, the lead Kepler systems engineer at Ball Aerospace & Technology Corp. in Boulder, Colo. Bachtell has been working on the design, development and testing of Kepler for nine years.

Kepler is a NASA Discovery mission. Ames is responsible for the ground system development, mission operations and science data analysis. JPL manages the Kepler mission development. Ball Aerospace & Technologies Corp. is responsible for developing the Kepler flight system and supporting mission operations.

posted 08-06-2009 01:30 PM

NASA's Kepler Mission Spies Changing Phases in a Distant World

NASA's new exoplanet-hunting Kepler space telescope has detected the atmosphere of a known giant gas planet, demonstrating the telescope's extraordinary scientific capabilities. The discovery will be published Friday in the journal Science.

The find is based on a relatively short 10 days of test data collected before the official start of science operations. Kepler was launched March 6, 2009, from Cape Canaveral Air Force Station in Florida. The observation demonstrates the extremely high precision of the measurements made by the telescope, even before its calibration and data analysis software were finished.

"As NASA's first exoplanets mission, Kepler has made a dramatic entrance on the planet-hunting scene," said Jon Morse, director of the Science Mission Directorate's Astrophysics Division at NASA Headquarters in Washington. "Detecting this planet's atmosphere in just the first 10 days of data is only a taste of things to come. The planet hunt is on!"

Kepler team members say these new data indicate the mission is indeed capable of finding Earth-like planets, if they exist. Kepler will spend the next three-and-a-half years searching for planets as small as Earth, including those that orbit stars in a warm zone where there could be water. It will do this by looking for periodic dips in the brightness of stars, which occur when orbiting planets transit, or cross in front of, the stars.

"When the light curves from tens of thousands of stars were shown to the Kepler science team, everyone was awed; no one had ever seen such exquisitely detailed measurements of the light variations of so many different types of stars," said William Borucki, the principal science investigator and lead author of the paper.

The observations were collected from a planet called HAT-P-7, known to transit a star located about 1,000 light years from Earth. The planet orbits the star in just 2.2 days and is 26 times closer than Earth is to the sun. Its orbit, combined with a mass somewhat larger than the planet Jupiter, classifies this planet as a "hot Jupiter." It is so close to its star, the planet is as hot as the glowing red heating element on a stove.

The Kepler measurements show the transit from the previously detected HAT-P-7. However, these new measurements are so precise, they also show a smooth rise and fall of the light between transits caused by the changing phases of the planet, similar to those of our moon. This is a combination of both the light emitted from the planet and the light reflected off the planet. The smooth rise and fall of light is also punctuated by a small drop in light, called an occultation, exactly halfway between each transit. An occultation happens when a planet passes behind a star.

The new Kepler data can be used to study this hot Jupiter in unprecedented detail. The depth of the occultation and the shape and amplitude of the light curve show the planet has an atmosphere with a day-side temperature of about 4,310 degrees Fahrenheit. Little of this heat is carried to the cool night side. The occultation time compared to the main transit time shows the planet has a circular orbit. The discovery of light from this planet confirms the predictions by researchers and theoretical models that the emission would be detectable by Kepler.

This new discovery also demonstrates Kepler has the precision to find Earth-size planets. The observed brightness variation is just one and a half times what is expected for a transit caused by an Earth-sized planet. Although this is already the highest precision ever obtained for an observation of this star, Kepler will be even more precise after analysis software being developed for the mission is completed.

"This early result shows the Kepler detection system is performing right on the mark," said David Koch, deputy principal investigator of NASA's Ames Research Center at Moffett Field, Calif. "It bodes well for Kepler's prospects to be able to detect Earth-size planets."

posted 01-04-2010 01:12 PM

NASA's Kepler Space Telescope Discovers Five Exoplanets

NASA's Kepler space telescope, designed to find Earth-size planets in the habitable zone of sun-like stars, has discovered its first five new exoplanets, or planets beyond our solar system.

Kepler's high sensitivity to both small and large planets enabled the discovery of the exoplanets, named Kepler 4b, 5b, 6b, 7b and 8b. The discoveries were announced Monday, Jan. 4, by the members of the Kepler science team during a news briefing at the American Astronomical Society meeting in Washington.

"These observations contribute to our understanding of how planetary systems form and evolve from the gas and dust disks that give rise to both the stars and their planets," said William Borucki of NASA's Ames Research Center in Moffett Field, Calif. Borucki is the mission's science principal investigator. "The discoveries also show that our science instrument is working well. Indications are that Kepler will meet all its science goals."

Known as "hot Jupiters" because of their high masses and extreme temperatures, the new exoplanets range in size from similar to Neptune to larger than Jupiter. They have orbits ranging from 3.3 to 4.9 days. Estimated temperatures of the planets range from 2,200 to 3,000 degrees Fahrenheit, hotter than molten lava and much too hot for life as we know it. All five of the exoplanets orbit stars hotter and larger than Earth's sun.

"It's gratifying to see the first Kepler discoveries rolling off the assembly line," said Jon Morse, director of the Astrophysics Division at NASA Headquarters in Washington. "We expected Jupiter-size planets in short orbits to be the first planets Kepler could detect. It's only a matter of time before more Kepler observations lead to smaller planets with longer period orbits, coming closer and closer to the discovery of the first Earth analog."

Launched on March 6, 2009, from Cape Canaveral Air Force Station in Florida, the Kepler mission continuously and simultaneously observes more than 150,000 stars. Kepler's science instrument, or photometer, already has measured hundreds of possible planet signatures that are being analyzed.

While many of these signatures are likely to be something other than a planet, such as small stars orbiting larger stars, ground-based observatories have confirmed the existence of the five exoplanets. The discoveries are based on approximately six weeks' worth of data collected since science operations began on May 12, 2009.

Kepler looks for the signatures of planets by measuring dips in the brightness of stars. When planets cross in front of, or transit, their stars as seen from Earth, they periodically block the starlight. The size of the planet can be derived from the size of the dip. The temperature can be estimated from the characteristics of the star it orbits and the planet's orbital period.

Kepler will continue science operations until at least November 2012. It will search for planets as small as Earth, including those that orbit stars in a warm habitable zone where liquid water could exist on the surface of the planet. Since transits of planets in the habitable zone of solar-like stars occur about once a year and require three transits for verification, it is expected to take at least three years to locate and verify an Earth-size planet.

According to Borucki, Kepler's continuous and long-duration search should greatly improve scientists' ability to determine the distributions of planet size and orbital period in the future. "Today's discoveries are a significant contribution to that goal," Borucki said. "The Kepler observations will tell us whether there are many stars with planets that could harbor life, or whether we might be alone in our galaxy."

Kepler is NASA's 10th Discovery mission. Ames is responsible for the ground system development, mission operations and science data analysis. NASA's Jet Propulsion Laboratory in Pasadena, Calif., managed the Kepler mission development. Ball Aerospace & Technologies Corp. of Boulder, Colo., was responsible for developing the Kepler flight system. Ball and the Laboratory for Atmospheric and Space Physics at the University of Colorado in Boulder are supporting mission operations.

Ground observations necessary to confirm the discoveries were conducted with ground-based telescopes the Keck I in Hawaii; Hobby-Ebberly and Harlan J. Smith 2.7m in Texas; Hale and Shane in California; WIYN, MMT and Tillinghast in Arizona; and Nordic Optical in the Canary Islands, Spain.

posted 08-03-2010 03:26 PM

Kepler Science Status: Statement to Ames Center Director

The following NASA statement was sent to Dr. S. Pete Worden, Director, NASA Ames Research Center from the Kepler Science Council on Aug. 2, 2010.

"Recently there have been reports to the effect that Kepler has discovered many Earth-like planets. This is not the case. Analysis of the current Kepler data does not support the assertion that Kepler has found any Earth-like planets.

Kepler is producing excellent results and is on a path to achieving all its mission requirements and actually determining the frequency of Earth-size planets, especially in habitable zones. We will announce our results when they become available and are confirmed."

Signed,

Edward W. Dunham, Kepler Science Team Lead
Thomas N. Gautier, Kepler Project Scientist
William J. Borucki, Kepler Principal Investigator

for the Kepler Science Council

posted 08-29-2010 11:35 AM

NASA's Kepler Mission Discovers Two Planets Transiting the Same Star

NASA's Kepler spacecraft has discovered the first confirmed planetary system with more than one planet crossing in front of, or transiting, the same star.

The transit signatures of two distinct planets were seen in the data for the sun-like star designated Kepler-9. The planets were named Kepler-9b and 9c. The discovery incorporates seven months of observations of more than 156,000 stars as part of an ongoing search for Earth-sized planets outside our solar system. The findings will be published in Thursday's issue of the journal Science.

Kepler's ultra-precise camera measures tiny decreases in the stars' brightness that occur when a planet transits them. The size of the planet can be derived from these temporary dips.

The distance of the planet from the star can be calculated by measuring the time between successive dips as the planet orbits the star. Small variations in the regularity of these dips can be used to determine the masses of planets and detect other non-transiting planets in the system.

In June, mission scientists submitted findings for peer review that identified more than 700 planet candidates in the first 43 days of Kepler data. The data included five additional candidate systems that appear to exhibit more than one transiting planet. The Kepler team recently identified a sixth target exhibiting multiple transits and accumulated enough follow-up data to confirm this multi-planet system.

"Kepler's high quality data and round-the-clock coverage of transiting objects enable a whole host of unique measurements to be made of the parent stars and their planetary systems," said Doug Hudgins, the Kepler program scientist at NASA Headquarters in Washington.

Scientists refined the estimates of the masses of the planets using observations from the W.M. Keck Observatory in Hawaii. The observations show Kepler-9b is the larger of the two planets, and both have masses similar to but less than Saturn. Kepler-9b lies closest to the star with an orbit of about 19 days, while Kepler-9c has an orbit of about 38 days. By observing several transits by each planet over the seven months of data, the time between successive transits could be analyzed.

"This discovery is the first clear detection of significant changes in the intervals from one planetary transit to the next, what we call transit timing variations," said Matthew Holman, a Kepler mission scientist from the Harvard-Smithsonian Center for Astrophysics in Cambridge, Mass. "This is evidence of the gravitational interaction between the two planets as seen by the Kepler spacecraft."

In addition to the two confirmed giant planets, Kepler scientists also have identified what appears to be a third, much smaller transit signature in the observations of Kepler-9. That signature is consistent with the transits of a super-Earth-sized planet about 1.5 times the radius of Earth in a scorching, near-sun 1.6 day-orbit. Additional observations are required to determine whether this signal is indeed a planet or an astronomical phenomenon that mimics the appearance of a transit.

posted 10-26-2010 11:52 AM

NASA's Kepler Spacecraft Takes Pulse Of Distant Stars

An international cadre of scientists that used data from NASA's Kepler spacecraft announced Tuesday the detection of stellar oscillations, or "starquakes," that yield new insights about the size, age and evolution of stars.

The results were presented at a news conference at Aarhus University in Denmark by scientists representing the Kepler Asteroseismic Science Consortium (KASC). The team studied thousands of stars observed by Kepler, releasing what amounts to a roster of some of humanity's most well-characterized stars.

Analysis of stellar oscillations is similar to how seismologists study earthquakes to probe the Earth's interior. This branch of science, called astroseismology, produces measurements of stars the Kepler science team is anxious to have.

"Using the unparalleled data provided by Kepler, KASC scientists are quite literally revolutionizing our understanding of stars and their structures," said Douglas Hudgins, Kepler Program Scientist at NASA Headquarters in Washington. "What's more, they are doing so at no cost to the American taxpayer. All the KASC scientists are supported by research funding from their home countries. It is a perfect illustration of the tremendous value that our international partners bring to NASA missions."

In the results presented Tuesday, one oscillating star took center stage: KIC 11026764 has the most accurately known properties of any star in the Kepler field. In fact, few stars in the universe are known to similar accuracy. At an age of 5.94 billion years, it has grown to a little over twice the diameter of the sun and will continue to do so as it transforms into a red giant. The oscillations reveal that this star is powered by hydrogen fusion in a thin shell around a helium-rich core.

"We are just about to enter a new area in stellar astrophysics," said Thomas Kallinger, lead author on a study of red giant stars and postdoctoral fellow at the Universities of British Columbia and Vienna. "Kepler provides us with data of such good quality that they will change our view of how stars work in detail."

KASC scientists also reported on the star RR Lyrae. It has been studied for more than 100 years as the first member of an important class of stars used to measure cosmological distances. The brightness, or light wave amplitude, of the star oscillates within a well-known period of about 13.5 hours. Yet during that period, other small cyclic changes in amplitude occur -- behavior known as the Blazhko effect.

The effect has puzzled astronomers for decades, but thanks to Kepler data, scientists may have a clue as to its origin. Kepler observations revealed an additional oscillation period that had never been previously detected. The oscillation occurs with a time scale twice as long as the 13.5-hour period. The Kepler data indicates the doubling is linked to the Blazhko effect.

"Kepler data ultimately will give us a better understanding of the future of our sun and the evolution of our galaxy as a whole," said Daniel Huber, lead author on one of the KASC studies.

Launched in March 2009, Kepler was designed to discover Earth-size planets orbiting other stars. The spacecraft uses a huge digital camera, known as a photometer, to continuously monitor the brightness of more than 150,000 stars in its field of view as it orbits around the sun. Kepler searches for distant worlds by looking for "transits," when a planet passes in front of a star, briefly causing it to dim. The amount of dimming reveals the size of the planet compared to the size of the star.

posted 01-10-2011 12:30 PM

NASA'S Kepler Mission Discovers Its First Rocky Planet

NASA's Kepler mission confirmed the discovery of its first rocky planet, named Kepler-10b. Measuring 1.4 times the size of Earth, it is the smallest planet ever discovered outside our solar system.

The discovery of this so-called exoplanet is based on more than eight months of data collected by the spacecraft from May 2009 to early January 2010.

"All of Kepler's best capabilities have converged to yield the first solid evidence of a rocky planet orbiting a star other than our sun," said Natalie Batalha, Kepler's deputy science team lead at NASA's Ames Research Center in Moffett Field, Calif., and primary author of a paper on the discovery accepted by the Astrophysical Journal. "The Kepler team made a commitment in 2010 about finding the telltale signatures of small planets in the data, and it's beginning to pay off."

Kepler's ultra-precise photometer measures the tiny decrease in a star's brightness that occurs when a planet crosses in front of it. The size of the planet can be derived from these periodic dips in brightness. The distance between the planet and the star is calculated by measuring the time between successive dips as the planet orbits the star.

Kepler is the first NASA mission capable of finding Earth-size planets in or near the habitable zone, the region in a planetary system where liquid water can exist on the planet's surface. However, since it orbits once every 0.84 days, Kepler-10b is more than 20 times closer to its star than Mercury is to our sun and not in the habitable zone.

Kepler-10 was the first star identified that could potentially harbor a small transiting planet, placing it at the top of the list for ground-based observations with the W.M. Keck Observatory 10-meter telescope in Hawaii.

Scientists waiting for a signal to confirm Kepler-10b as a planet were not disappointed. Keck was able to measure tiny changes in the star's spectrum, called Doppler shifts, caused by the telltale tug exerted by the orbiting planet on the star.

"The discovery of Kepler 10-b is a significant milestone in the search for planets similar to our own," said Douglas Hudgins, Kepler program scientist at NASA Headquarters in Washington. "Although this planet is not in the habitable zone, the exciting find showcases the kinds of discoveries made possible by the mission and the promise of many more to come," he said.

Knowledge of the planet is only as good as the knowledge of the star it orbits. Because Kepler-10 is one of the brighter stars being targeted by Kepler, scientists were able to detect high frequency variations in the star's brightness generated by stellar oscillations, or starquakes. This analysis allowed scientists to pin down Kepler-10b's properties.

There is a clear signal in the data arising from light waves that travel within the interior of the star. Kepler Asteroseismic Science Consortium scientists use the information to better understand the star, just as earthquakes are used to learn about Earth's interior structure. As a result of this analysis, Kepler-10 is one of the most well characterized planet-hosting stars in the universe.

That's good news for the team studying Kepler-10b. Accurate stellar properties yield accurate planet properties. In the case of Kepler-10b, the picture that emerges is of a rocky planet with a mass 4.6 times that of Earth and with an average density of 8.8 grams per cubic centimeter -- similar to that of an iron dumbbell.

Ames manages Kepler's ground system development, mission operations and science data analysis. NASA's Jet Propulsion Laboratory in Pasadena, Calif., managed Kepler mission development.

Ball Aerospace and Technologies Corp. in Boulder, Colo., developed the Kepler flight system and supports mission operations with the Laboratory for Atmospheric and Space Physics at the University of Colorado in Boulder. The Space Telescope Science Institute in Baltimore archives, hosts and distributes the Kepler science data.

posted 02-02-2011 12:44 PM

NASA Finds Earth-Size Planet Candidates In Habitable Zone, Six Planet System

NASA's Kepler mission has discovered its first Earth-size planet candidates and its first candidates in the habitable zone, a region where liquid water could exist on a planet's surface. Five of the potential planets are near Earth-size and orbit in the habitable zone of smaller, cooler stars than our sun.

Candidates require follow-up observations to verify they are actual planets. Kepler also found six confirmed planets orbiting a sun-like star, Kepler-11. This is the largest group of transiting planets orbiting a single star yet discovered outside our solar system.

"In one generation we have gone from extraterrestrial planets being a mainstay of science fiction, to the present, where Kepler has helped turn science fiction into today's reality," said NASA Administrator Charles Bolden. "These discoveries underscore the importance of NASA's science missions, which consistently increase understanding of our place in the cosmos."

The discoveries are part of several hundred new planet candidates identified in new Kepler mission science data, released on Tuesday, Feb. 1. The findings increase the number of planet candidates identified by Kepler to-date to 1,235. Of these, 68 are approximately Earth-size; 288 are super-Earth-size; 662 are Neptune-size; 165 are the size of Jupiter and 19 are larger than Jupiter.

Of the 54 new planet candidates found in the habitable zone, five are near Earth-sized. The remaining 49 habitable zone candidates range from super-Earth size -- up to twice the size of Earth -- to larger than Jupiter.

The findings are based on the results of observations conducted May 12 to Sept. 17, 2009, of more than 156,000 stars in Kepler's field of view, which covers approximately 1/400 of the sky.

"The fact that we've found so many planet candidates in such a tiny fraction of the sky suggests there are countless planets orbiting sun-like stars in our galaxy," said William Borucki of NASA's Ames Research Center in Moffett Field, Calif., the mission's science principal investigator. "We went from zero to 68 Earth-sized planet candidates and zero to 54 candidates in the habitable zone, some of which could have moons with liquid water."

Among the stars with planetary candidates, 170 show evidence of multiple planetary candidates. Kepler-11, located approximately 2,000 light years from Earth, is the most tightly packed planetary system yet discovered. All six of its confirmed planets have orbits smaller than Venus, and five of the six have orbits smaller than Mercury's. The only other star with more than one confirmed transiting planet is Kepler-9, which has three. The Kepler-11 findings will be published in the Feb. 3 issue of the journal Nature.

"Kepler-11 is a remarkable system whose architecture and dynamics provide clues about its formation," said Jack Lissauer, a planetary scientist and Kepler science team member at Ames. "These six planets are mixtures of rock and gases, possibly including water. The rocky material accounts for most of the planets' mass, while the gas takes up most of their volume. By measuring the sizes and masses of the five inner planets, we determined they are among the lowest mass confirmed planets beyond our solar system."

All of the planets orbiting Kepler-11 are larger than Earth, with the largest ones being comparable in size to Uranus and Neptune. The innermost planet, Kepler-11b, is ten times closer to its star than Earth is to the sun. Moving outward, the other planets are Kepler-11c, Kepler-11d, Kepler-11e, Kepler-11f, and the outermost planet, Kepler-11g, which is half as far from its star as Earth is from the sun.

The planets Kepler-11d, Kepler-11e and Kepler-11f have a significant amount of light gas, which indicates that they formed within a few million years of the system's formation.

"The historic milestones Kepler makes with each new discovery will determine the course of every exoplanet mission to follow," said Douglas Hudgins, Kepler program scientist at NASA Headquarters in Washington.

Kepler, a space telescope, looks for planet signatures by measuring tiny decreases in the brightness of stars caused by planets crossing in front of them. This is known as a transit.

Since transits of planets in the habitable zone of sun-like stars occur about once a year and require three transits for verification, it is expected to take three years to locate and verify Earth-size planets orbiting sun-like stars.

The Kepler science team uses ground-based telescopes and the Spitzer Space Telescope to review observations on planetary candidates and other objects of interest the spacecraft finds.

The star field that Kepler observes in the constellations Cygnus and Lyra can only be seen from ground-based observatories in spring through early fall. The data from these other observations help determine which candidates can be validated as planets.

posted 09-15-2011 02:20 PM

NASA's Kepler Discovery Confirms First Planet Orbiting Two Stars

The existence of a world with a double sunset, as portrayed in the film Star Wars more than 30 years ago, is now scientific fact. NASA's Kepler mission has made the first unambiguous detection of a circumbinary planet — a planet orbiting two stars — 200 light-years from Earth.

Unlike Star Wars' Tatooine, the planet is cold, gaseous and not thought to harbor life, but its discovery demonstrates the diversity of planets in our galaxy. Previous research has hinted at the existence of circumbinary planets, but clear confirmation proved elusive. Kepler detected such a planet, known as Kepler-16b, by observing transits, where the brightness of a parent star dims from the planet crossing in front of it.

"This discovery confirms a new class of planetary systems that could harbor life," Kepler principal investigator William Borucki said. "Given that most stars in our galaxy are part of a binary system, this means the opportunities for life are much broader than if planets form only around single stars. This milestone discovery confirms a theory that scientists have had for decades but could not prove until now."

A research team led by Laurance Doyle of the SETI Institute in Mountain View, Calif., used data from the Kepler space telescope, which measures dips in the brightness of more than 150,000 stars, to search for transiting planets. Kepler is the first NASA mission capable of finding Earth-size planets in or near the "habitable zone," the region in a planetary system where liquid water can exist on the surface of the orbiting planet.

Scientists detected the new planet in the Kepler-16 system, a pair of orbiting stars that eclipse each other from our vantage point on Earth. When the smaller star partially blocks the larger star, a primary eclipse occurs, and a secondary eclipse occurs when the smaller star is occulted, or completely blocked, by the larger star.

Astronomers further observed that the brightness of the system dipped even when the stars were not eclipsing one another, hinting at a third body. The additional dimming in brightness events, called the tertiary and quaternary eclipses, reappeared at irregular intervals of time, indicating the stars were in different positions in their orbit each time the third body passed. This showed the third body was circling, not just one, but both stars, in a wide circumbinary orbit.

The gravitational tug on the stars, measured by changes in their eclipse times, was a good indicator of the mass of the third body. Only a very slight gravitational pull was detected, one that only could be caused by a small mass. The findings are described in a new study published Friday, Sept. 16, in the journal Science.

"Most of what we know about the sizes of stars comes from such eclipsing binary systems, and most of what we know about the size of planets comes from transits," said Doyle, who also is the lead author and a Kepler participating scientist. "Kepler-16 combines the best of both worlds, with stellar eclipses and planetary transits in one system."

This discovery confirms that Kepler-16b is an inhospitable, cold world about the size of Saturn and thought to be made up of about half rock and half gas. The parent stars are smaller than our sun. One is 69 percent the mass of the sun and the other only 20 percent. Kepler-16b orbits around both stars every 229 days, similar to Venus' 225-day orbit, but lies outside the system's habitable zone, where liquid water could exist on the surface, because the stars are cooler than our sun.

"Working in film, we often are tasked with creating something never before seen," said visual effects supervisor John Knoll of Industrial Light & Magic, a division of Lucasfilm Ltd., in San Francisco. "However, more often than not, scientific discoveries prove to be more spectacular than anything we dare imagine. There is no doubt these discoveries influence and inspire storytellers. Their very existence serves as cause to dream bigger and open our minds to new possibilities beyond what we think we 'know.'"

posted 12-05-2011 11:58 AM

NASA's Kepler Confirms Its First Planet in Habitable Zone of Sun-Like Star

NASA's Kepler mission has confirmed its first planet in the "habitable zone," the region where liquid water could exist on a planet’s surface. Kepler also has discovered more than 1,000 new planet candidates, nearly doubling its previously known count. Ten of these candidates are near-Earth-size and orbit in the habitable zone of their host star. Candidates require follow-up observations to verify they are actual planets.

The newly confirmed planet, Kepler-22b, is the smallest yet found to orbit in the middle of the habitable zone of a star similar to our sun. The planet is about 2.4 times the radius of Earth. Scientists don't yet know if Kepler-22b has a predominantly rocky, gaseous or liquid composition, but its discovery is a step closer to finding Earth-like planets.

Previous research hinted at the existence of near-Earth-size planets in habitable zones, but clear confirmation proved elusive. Two other small planets orbiting stars smaller and cooler than our sun recently were confirmed on the very edges of the habitable zone, with orbits more closely resembling those of Venus and Mars.

"This is a major milestone on the road to finding Earth's twin," said Douglas Hudgins, Kepler program scientist at NASA Headquarters in Washington. "Kepler's results continue to demonstrate the importance of NASA's science missions, which aim to answer some of the biggest questions about our place in the universe."

Kepler discovers planets and planet candidates by measuring dips in the brightness of more than 150,000 stars to search for planets that cross in front, or "transit," the stars. Kepler requires at least three transits to verify a signal as a planet.

"Fortune smiled upon us with the detection of this planet," said William Borucki, Kepler principal investigator at NASA Ames Research Center at Moffett Field, Calif., who led the team that discovered Kepler-22b. "The first transit was captured just three days after we declared the spacecraft operationally ready. We witnessed the defining third transit over the 2010 holiday season."

The Kepler science team uses ground-based telescopes and the Spitzer Space Telescope to review observations on planet candidates the spacecraft finds. The star field that Kepler observes in the constellations Cygnus and Lyra can only be seen from ground-based observatories in spring through early fall. The data from these other observations help determine which candidates can be validated as planets.

Kepler-22b is located 600 light-years away. While the planet is larger than Earth, its orbit of 290 days around a sun-like star resembles that of our world. The planet's host star belongs to the same class as our sun, called G-type, although it is slightly smaller and cooler.

Of the 54 habitable zone planet candidates reported in February 2011, Kepler-22b is the first to be confirmed. This milestone will be published in The Astrophysical Journal.

The Kepler team is hosting its inaugural science conference at Ames Dec. 5-9, announcing 1,094 new planet candidate discoveries. Since the last catalog was released in February, the number of planet candidates identified by Kepler has increased by 89 percent and now totals 2,326. Of these, 207 are approximately Earth-size, 680 are super Earth-size, 1,181 are Neptune-size, 203 are Jupiter-size and 55 are larger than Jupiter.

The findings, based on observations conducted May 2009 to September 2010, show a dramatic increase in the numbers of smaller-size planet candidates.

Kepler observed many large planets in small orbits early in its mission, which were reflected in the February data release. Having had more time to observe three transits of planets with longer orbital periods, the new data suggest that planets one to four times the size of Earth may be abundant in the galaxy.

The number of Earth-size and super Earth-size candidates has increased by more than 200 and 140 percent since February, respectively.

There are 48 planet candidates in their star's habitable zone. While this is a decrease from the 54 reported in February, the Kepler team has applied a stricter definition of what constitutes a habitable zone in the new catalog, to account for the warming effect of atmospheres, which would move the zone away from the star, out to longer orbital periods.

"The tremendous growth in the number of Earth-size candidates tells us that we're honing in on the planets Kepler was designed to detect: those that are not only Earth-size, but also are potentially habitable," said Natalie Batalha, Kepler deputy science team lead at San Jose State University in California. "The more data we collect, the keener our eye for finding the smallest planets out at longer orbital periods."

posted 12-20-2011 02:42 PM

NASA Discovers First Earth-Size Planets Beyond Our Solar System

NASA's Kepler mission has discovered the first Earth-size planets orbiting a sun-like star outside our solar system. The planets, called Kepler-20e and Kepler-20f, are too close to their star to be in the so-called habitable zone where liquid water could exist on a planet's surface, but they are the smallest exoplanets ever confirmed around a star like our sun.

The discovery marks the next important milestone in the ultimate search for planets like Earth. The new planets are thought to be rocky. Kepler-20e is slightly smaller than Venus, measuring 0.87 times the radius of Earth. Kepler-20f is slightly larger than Earth, measuring 1.03 times its radius. Both planets reside in a five-planet system called Kepler-20, approximately 1,000 light-years away in the constellation Lyra.

Kepler-20e orbits its parent star every 6.1 days and Kepler-20f every 19.6 days. These short orbital periods mean very hot, inhospitable worlds. Kepler-20f, at 800 degrees Fahrenheit, is similar to an average day on the planet Mercury. The surface temperature of Kepler-20e, at more than 1,400 degrees Fahrenheit, would melt glass.

“The primary goal of the Kepler mission is to find Earth-sized planets in the habitable zone," said Francois Fressin of the Harvard-Smithsonian Center for Astrophysics in Cambridge, Mass., lead author of a new study published in the journal Nature. "This discovery demonstrates for the first time that Earth-size planets exist around other stars, and that we are able to detect them.”

The Kepler-20 system includes three other planets that are larger than Earth but smaller than Neptune. Kepler-20b, the closest planet, Kepler-20c, the third planet, and Kepler-20d, the fifth planet, orbit their star every 3.7, 10.9 and 77.6 days. All five planets have orbits lying roughly within Mercury's orbit in our solar system. The host star belongs to the same G-type class as our sun, although it is slightly smaller and cooler.

The system has an unexpected arrangement. In our solar system, small, rocky worlds orbit close to the sun and large, gaseous worlds orbit farther out. In comparison, the planets of Kepler-20 are organized in alternating size: large, small, large, small and large.

"The Kepler data are showing us some planetary systems have arrangements of planets very different from that seen in our solar system," said Jack Lissauer, planetary scientist and Kepler science team member at NASA's Ames Research Center in Moffett Field, Calif. "The analysis of Kepler data continue to reveal new insights about the diversity of planets and planetary systems within our galaxy."

Scientists are not certain how the system evolved but they do not think the planets formed in their existing locations. They theorize the planets formed farther from their star and then migrated inward, likely through interactions with the disk of material from which they originated. This allowed the worlds to maintain their regular spacing despite alternating sizes.

The Kepler space telescope detects planets and planet candidates by measuring dips in the brightness of more than 150,000 stars to search for planets crossing in front, or transiting, their stars. The Kepler science team requires at least three transits to verify a signal as a planet.

The Kepler science team uses ground-based telescopes and the Spitzer Space Telescope to review observations on planet candidates the spacecraft finds. The star field Kepler observes in the constellations Cygnus and Lyra can be seen only from ground-based observatories in spring through early fall. The data from these other observations help determine which candidates can be validated as planets.

To validate Kepler-20e and Kepler-20f, astronomers used a computer program called Blender, which runs simulations to help rule out other astrophysical phenomena masquerading as a planet.

On Dec. 5 the team announced the discovery of Kepler-22b in the habitable zone of its parent star. It is likely to be too large to have a rocky surface. While Kepler-20e and Kepler-20f are Earth-size, they are too close to their parent star to have liquid water on the surface.

"In the cosmic game of hide and seek, finding planets with just the right size and just the right temperature seems only a matter of time," said Natalie Batalha, Kepler deputy science team lead and professor of astronomy and physics at San Jose State University. "We are on the edge of our seats knowing that Kepler's most anticipated discoveries are still to come."

posted 01-12-2012 10:46 AM

NASA's Kepler Mission Finds Three Smallest Exoplanets

Astronomers using data from NASA's Kepler mission have discovered the three smallest planets yet detected orbiting a star beyond our sun. The planets orbit a single star, called KOI-961, and are 0.78, 0.73 and 0.57 times the radius of Earth. The smallest is about the size of Mars.

All three planets are thought to be rocky like Earth, but orbit close to their star. That makes them too hot to be in the habitable zone, which is the region where liquid water could exist. Of the more than 700 planets confirmed to orbit other stars -- called exoplanets -- only a handful are known to be rocky.

"Astronomers are just beginning to confirm thousands of planet candidates uncovered by Kepler so far," said Doug Hudgins, Kepler program scientist at NASA Headquarters in Washington. "Finding one as small as Mars is amazing, and hints that there may be a bounty of rocky planets all around us."

Kepler searches for planets by continuously monitoring more than 150,000 stars, looking for telltale dips in their brightness caused by crossing, or transiting, planets. At least three transits are required to verify a signal as a planet. Follow-up observations from ground-based telescopes also are needed to confirm the discoveries.

The latest discovery comes from a team led by astronomers at the California Institute of Technology in Pasadena. The team used data publicly released by the Kepler mission, along with follow-up observations from the Palomar Observatory, near San Diego, and the W.M. Keck Observatory atop Mauna Kea in Hawaii. Their measurements dramatically revised the sizes of the planets from what originally was estimated.

The three planets are very close to their star, taking less than two days to orbit around it. The KOI-961 star is a red dwarf with a diameter one-sixth that of our sun, making it just 70 percent bigger than Jupiter.

"This is the tiniest solar system found so far," said John Johnson, the principal investigator of the research from NASA's Exoplanet Science Institute at the California Institute of Technology in Pasadena. "It's actually more similar to Jupiter and its moons in scale than any other planetary system. The discovery is further proof of the diversity of planetary systems in our galaxy."

Red dwarfs are the most common kind of star in our Milky Way galaxy. The discovery of three rocky planets around one red dwarf suggests that the galaxy could be teeming with similar rocky planets.

"These types of systems could be ubiquitous in the universe," said Phil Muirhead, lead author of the new study from Caltech. "This is a really exciting time for planet hunters."

The discovery follows a string of recent milestones for the Kepler mission. In December 2011, scientists announced the mission's first confirmed planet in the habitable zone of a sun-like star: a planet 2.4 times the size of Earth called Kepler-22b. Later in the month, the team announced the discovery of the first Earth-size planets orbiting a sun-like star outside our solar system, called Kepler-20e and Kepler-20f.

For the latest discovery, the team obtained the sizes of the three planets called KOI-961.01, KOI-961.02 and KOI-961.03 with the help of a well-studied twin star to KOI-961, or Barnard's Star. By better understanding the KOI-961 star, they then could determine how big the planets must be to have caused the observed dips in starlight. In addition to the Kepler observations and ground-based telescope measurements, the team used modeling techniques to confirm the planet discoveries.

Prior to these confirmed planets, only six other planets had been confirmed using the Kepler public data.

posted 04-05-2012 12:11 AM

NASA's Kepler Mission Awarded Mission Extension

NASA's Kepler mission has been approved for extension through fiscal year 2016 based on a recommendation from the agency's senior review of its operating missions. The extension provides four additional years to find Earth-size planets in the habitable zone — the region in a planetary system where liquid water could exist on the surface of an orbiting planet — around sun-like stars in our galaxy.

"Kepler has revolutionized our understanding of exoplanets and the study of stellar seismology and variability," said Roger Hunter, Kepler project manager at NASA Ames Research Center, Moffett Field, Calif. "There is currently no other mission in development that can replace or surpass the precision of Kepler. This extended mission will afford Kepler a unique opportunity to rewrite our understanding of the galaxy and our place in it."

Launched in March 2009, the Kepler spacecraft identifies planet candidates by repeatedly measuring the tiny change in brightness of more than 150,000 stars to detect when a planet transits the face of the star. The size of the planet can be derived from these periodic dips in brightness. At least three transits are required to verify a signal as a planet.

"Kepler offers a new technical capability, opening a new measurement parameter space, and as often happens with such developments, that has led to unexpected results... There has been a continuous stream of new findings — the assimilation and exploitation of new opportunities is just beginning," as stated by the committee in the 2012 Senior Review report.

The mission's discoveries beyond our solar system include the first unquestionably rocky planet; the first multiple-transiting planet system; the first small planet in the habitable zone; the first Earth-size planets; the smallest Mars-size planets; and the confirmation of a new class of double-star planetary systems.

posted 11-15-2012 08:15 AM

NASA's Kepler Completes Prime Mission, Begins Extended Mission

NASA is marking two milestones in the search for planets like Earth; the successful completion of the Kepler Space Telescope's 3 1/2- year prime mission and the beginning of an extended mission that could last as long as four years.

Scientists have used Kepler data to identify more than 2,300 planet candidates and confirm more than 100 planets. Kepler is teaching us the galaxy is teeming with planetary systems and planets are prolific, and giving us hints that nature makes small planets efficiently.

So far, hundreds of Earth-size planet candidates have been found as well as candidates that orbit in the habitable zone, the region in a planetary system where liquid water might exist on the surface of a planet. None of the candidates is exactly like Earth. With the completion of the prime mission, Kepler now has collected enough data to begin finding true sun-Earth analogs -- Earth-size planets with a one-year orbit around stars similar to the sun.

"The initial discoveries of the Kepler mission indicate at least a third of the stars have planets and the number of planets in our galaxy must number in the billions," said William Borucki, Kepler principal investigator at NASA's Ames Research Center in Moffett Field, Calif. "The planets of greatest interest are other Earths and these could already be in the data awaiting analysis. Kepler's most exciting results are yet to come."

NASA's Kepler Space Telescope searches for planet candidates orbiting distant suns, or exoplanets, by continuously measuring the brightness of more than 150,000 stars. When a planet candidate passes, or transits, in front of the star from the spacecraft's vantage point, light from the star is blocked. Different sized planets block different amounts of starlight. The amount of starlight blocked by a planet reveals its size relative to its star.

Kepler was launched March 6, 2009. Its mission was to survey a portion of the galaxy to determine what fraction of stars might harbor potentially habitable, Earth-sized planets. Planets orbiting in or near habitable zones are of particular interest.

Kepler began the search for small worlds like our own on May 12, 2009, after two months of commissioning. Within months, five exoplanets, known as hot Jupiters because of their enormous size and orbits close to their stars, were confirmed.

Results from Kepler data continue to expand our understanding of planets and planetary systems. Highlights from the prime mission include:

• In August 2010, scientists confirmed the discovery of the first planetary system with more than one planet transiting the same star. The Kepler-9 system opened the door to measurement of gravitational interactions between planets as observed by the variations in their transit timing. This powerful new technique enables astronomers, in many cases, to calculate the mass of planets directly from Kepler data, without the need for follow-up observations from the ground.

• In January 2011, the Kepler team announced the discovery of the first unquestionably rocky planet outside the solar system. Kepler-10b, measuring 1.4 times the size of Earth, is the smallest confirmed planet with both a radius and mass measurement. Kepler has continued to uncover smaller and smaller planets, some almost as small as Mars, which tells us small rocky worlds may be common in the galaxy.

• In February 2011, scientists announced Kepler had found a very crowded and compact planetary system – a star with multiple transiting planets. Kepler-11 has six planets larger than Earth, all orbiting closer to their star than Venus orbits our sun. This and other subsequently identified compact multi-planet systems have orbital spacing relative to their host sun and neighboring planets unlike anything envisioned prior to the mission.

• In September 2011, Kepler data confirmed the existence of a world with a double sunset like the one famously portrayed in the film "Star Wars" more than 35 years ago. The discovery of Kepler-16b turned science fiction into science fact. Since then, the discoveries of six additional worlds orbiting double stars further demonstrated planets can form and persist in the environs of a double-star system.

• In December 2011, NASA announced Kepler's discovery of the mission's first planet in a habitable zone. Kepler-22b, about 2.4 times the size of Earth, is the smallest-radius planet yet found to orbit a sun-like star in the habitable zone. This discovery confirmed that we are getting continually closer to finding planets like our own.

• In February 2012, the Kepler team announced more than 1,000 new transiting planet candidates for a cumulative total of 2,321. The data continues the trend toward identifying smaller planets at longer orbital periods, similar to Earth. The results include hundreds of planetary systems.

• Recently, citizen scientists participating in Planet Hunters, a program led by Yale University that enlists the public to comb through Kepler data for signs of transiting planets, made their first planet discovery. The joint effort of amateur astronomers and scientists led to the first reported case of a planet orbiting a double star. The three bodies in turn are being orbited by a second distant pair of stars.

"Kepler's bounty of new planet discoveries, many quite different from anything found previously, will continue to astound," said Jack Lissauer, planetary scientist at Ames. "But to me, the most wonderful discovery of the mission has not been individual planets, but the systems of two, three, even six planets crowded close to their stars, and, like the planets orbiting about our sun, moving in nearly the same plane. Like people, planets interact with their neighbors and can be greatly affected by them. What are the neighborhoods of Earth-size exoplanets like? This is the question I most hope Kepler will answer in the years to come."

In April 2012, NASA awarded Kepler an extended mission through as late as 2016. More time will enable the continued the search for worlds like our own -- worlds that are not too far and too close to their sun.

"The Earth isn't unique, nor the center of the universe," said Geoff Marcy, professor of astronomy at the University of California at Berkeley. "The diversity of other worlds is greater than depicted in all the science fiction novels and movies. Aristotle would be proud of us for answering some of the most profound philosophical questions about our place in the universe."

posted 05-15-2013 03:23 PM

Kepler Mission Manager Update

At our semi-weekly contact on Tuesday, May 14, 2013, we found the Kepler spacecraft once again in safe mode. As was the case earlier this month, this was a Thruster-Controlled Safe Mode. The root cause is not yet known, however the proximate cause appears to be an attitude error. The spacecraft was oriented with the solar panels facing the sun, slowly spinning about the sun-line. The communication link comes and goes as the spacecraft spins.

We attempted to return to reaction wheel control as the spacecraft rotated into communication, and commanded a stop rotation. Initially, it appeared that all three wheels responded and that rotation had been successfully stopped, but reaction wheel 4 remained at full torque while the spin rate dropped to zero. This is a clear indication that there has been an internal failure within the reaction wheel, likely a structural failure of the wheel bearing. The spacecraft was then transitioned back to Thruster-Controlled Safe Mode.

An Anomaly Review Board concurred that the data appear to unambiguously indicate a wheel 4 failure, and that the team’s priority is to complete preparations to enter Point Rest State. Point Rest State is a loosely-pointed, thruster-controlled state that minimizes fuels usage while providing a continuous X-band communication downlink. The software to execute that state was loaded to the spacecraft last week, and last night the team completed the upload of the parameters the software will use.

The spacecraft is stable and safe, if still burning fuel. Our fuel budget is sufficient that we can take due caution while we finish our planning. In its current mode, our fuel will last for several months. Point Rest State would extend that period to years.

We have requested and received additional NASA Deep Space Network communication coverage, and this morning the Anomaly Review Board approved the transition to Point Rest State later today. Because this is a new operating mode of the spacecraft, the team will closely monitor the spacecraft, but no other immediate actions are planned. We will take the next several days and weeks to assess our options and develop new command products. These options are likely to include steps to attempt to recover wheel functionality and to investigate the utility of a hybrid mode, using both wheels and thrusters.

With the failure of a second reaction wheel, it's unlikely that the spacecraft will be able to return to the high pointing accuracy that enables its high-precision photometry. However, no decision has been made to end data collection.

Kepler had successfully completed its primary three-and-a-half year mission and entered an extended mission phase in November 2012.

Even if data collection were to end, the mission has substantial quantities of data on the ground yet to be fully analyzed, and the string of scientific discoveries is expected to continue for years to come.

Updates will be provided as information is available.

posted 05-23-2013 10:01 AM

Kepler Mission Manager Update

Following the apparent failure of reaction wheel 4 on May 11, 2013, engineers were successful at transitioning the spacecraft from a Thruster-Controlled Safe Mode to Point Rest State at approximately 3:30 p.m. PDT on Wednesday, May 15, 2013. The spacecraft has remained safe and stable in this attitude and is no longer considered to be in a critical situation.

As part of a normal spacecraft response to a pointing error, redundant electronics were automatically powered off to isolate them as a possible cause. However, once the team recovered the spacecraft to Point Rest State (PRS) and exonerated those systems, they were turned back on, providing full redundancy to the spacecraft. The reaction wheels remain offline. The photometer, which was turned off to reduce the power load, will be turned back on in the near future to keep thermal conditions of the spacecraft within nominal operating parameters. Kepler is not in science data collection.

PRS was developed in order to preserve fuel for an eventual recovery effort once a second wheel failed. This state uses thrusters to control the pointing of the spacecraft, tipping it towards the sun and letting the solar pressure tip it back away, resembling the motion of a pendulum. This is a very fuel-efficient mode, and it also provides an on-demand telemetry link to allow engineers to monitor and command the spacecraft. With nearly a week of PRS operations, the fuel usage appears to be on the low end of our estimates, allowing time for recovery planning.

The operations staff at Ball Aerospace did a wonderful job at developing and implementing PRS. As a result, the spacecraft is not in an emergency condition, and work can be conducted at a more deliberate pace. For the next week or so, we will contact the spacecraft on a daily basis to ensure PRS continues to operate as expected.

Over the coming weeks, an anomaly response team (ART) will evaluate wheel recovery options. The ART includes members from NASA Ames, Ball Aerospace, the Jet Propulsion Laboratory and UTC, the wheel manufacturer. This team has access to a broader reach of experts throughout NASA and industry, and will manage the wheel recovery efforts.

The team will continue to analyze recent telemetry received from the spacecraft. This analysis, and any planned recovery actions, will take time, and will likely be on the order of weeks, possibly months. Any planned commanding will first be vetted on the spacecraft test bed to validate command operability.

For now, PRS is working very well and keeping Kepler safe. We will provide updates on significant changes as the plan develops.

posted 08-15-2013 01:21 PM

NASA Ends Attempts to Fully Recover Kepler Spacecraft, Potential New Missions Considered

Following months of analysis and testing, the Kepler Space Telescope team is ending its attempts to restore the spacecraft to full working order, and now is considering what new science research it can carry out in its current condition.

Two of Kepler's four gyroscope-like reaction wheels, which are used to precisely point the spacecraft, have failed. The first was lost in July 2012, and the second in May. Engineers' efforts to restore at least one of the wheels have been unsuccessful.

Kepler completed its prime mission in November 2012 and began its four-year extended mission at that time. However, the spacecraft needs three functioning wheels to continue its search for Earth-sized exoplanets, which are planets outside our solar system, orbiting stars like our sun in what's known as the habitable zone -- the range of distances from a star where the surface temperature of a planet might be suitable for liquid water. As scientists analyze previously collected data, the Kepler team also is looking into whether the space telescope can conduct a different type of science program, including an exoplanet search, using the remaining two good reaction wheels and thrusters.

"Kepler has made extraordinary discoveries in finding exoplanets including several super-Earths in the habitable zone," said John Grunsfeld, associate administrator for NASA's Science Mission Directorate in Washington. "Knowing that Kepler has successfully collected all the data from its prime mission, I am confident that more amazing discoveries are on the horizon."

On Aug. 8, engineers conducted a system-level performance test to evaluate Kepler's current capabilities. They determined wheel 2, which failed last year, can no longer provide the precision pointing necessary for science data collection. The spacecraft was returned to its point rest state, which is a stable configuration where Kepler uses thrusters to control its pointing with minimal fuel use.

"At the beginning of our mission, no one knew if Earth-size planets were abundant in the galaxy. If they were rare, we might be alone," said William Borucki, Kepler science principal investigator at NASA's Ames Research Center in Moffett Field, Calif. "Now at the completion of Kepler observations, the data holds the answer to the question that inspired the mission: Are Earths in the habitable zone of stars like our sun common or rare?

An engineering study will be conducted on the modifications required to manage science operations with the spacecraft using a combination of its remaining two good reaction wheels and thrusters for spacecraft attitude control.

Informed by contributions from the broader science community in response to the call for scientific white papers announced Aug. 2, the Kepler project team will perform a study to identify possible science opportunities for a two-wheel Kepler mission.

Depending on the outcome of these studies, which are expected to be completed later this year, NASA will assess the scientific priority of a two-wheel Kepler mission. Such an assessment may include prioritization relative to other NASA astrophysics missions competing for operational funding at the NASA Senior Review board early next year.

From the data collected in the first half of its mission, Kepler has confirmed 135 exoplanets and identified over 3,500 candidates. The team continues to analyze all four years of collected data, expecting hundreds, if not thousands, of new discoveries including the long-awaited Earth-size planets in the habitable zone of sun-like stars. Though the spacecraft will no longer operate with its unparalleled precision pointing, scientists expect Kepler’s most interesting discoveries are still to come.

Meanwhile, preparations are underway for hosting the second Kepler Science Conference Nov. 4-8, at NASA's Ames Research Center. This will be an opportunity to share not only the investigations of the Kepler project team, but also those of the wider science community using publicly accessible data from Kepler. Registration is now open.

posted 02-27-2014 04:56 AM

NASA's Kepler Mission Announces a Planet Bonanza, 715 New Worlds

NASA's Kepler mission announced Wednesday the discovery of 715 new planets. These newly-verified worlds orbit 305 stars, revealing multiple-planet systems much like our own solar system.

Nearly 95 percent of these planets are smaller than Neptune, which is almost four times the size of Earth. This discovery marks a significant increase in the number of known small-sized planets more akin to Earth than previously identified exoplanets, which are planets outside our solar system.

"The Kepler team continues to amaze and excite us with their planet hunting results," said John Grunsfeld, associate administrator for NASA's Science Mission Directorate in Washington. "That these new planets and solar systems look somewhat like our own, portends a great future when we have the James Webb Space Telescope in space to characterize the new worlds.”

Since the discovery of the first planets outside our solar system roughly two decades ago, verification has been a laborious planet-by-planet process. Now, scientists have a statistical technique that can be applied to many planets at once when they are found in systems that harbor more than one planet around the same star.

To verify this bounty of planets, a research team co-led by Jack Lissauer, planetary scientist at NASA's Ames Research Center in Moffett Field, Calif., analyzed stars with more than one potential planet, all of which were detected in the first two years of Kepler's observations -- May 2009 to March 2011.

The research team used a technique called verification by multiplicity, which relies in part on the logic of probability. Kepler observes 150,000 stars, and has found a few thousand of those to have planet candidates. If the candidates were randomly distributed among Kepler's stars, only a handful would have more than one planet candidate. However, Kepler observed hundreds of stars that have multiple planet candidates. Through a careful study of this sample, these 715 new planets were verified.

This method can be likened to the behavior we know of lions and lionesses. In our imaginary savannah, the lions are the Kepler stars and the lionesses are the planet candidates. The lionesses would sometimes be observed grouped together whereas lions tend to roam on their own. If you see two lions it could be a lion and a lioness or it could be two lions. But if more than two large felines are gathered, then it is very likely to be a lion and his pride. Thus, through multiplicity the lioness can be reliably identified in much the same way multiple planet candidates can be found around the same star.

"Four years ago, Kepler began a string of announcements of first hundreds, then thousands, of planet candidates --but they were only candidate worlds," said Lissauer. "We've now developed a process to verify multiple planet candidates in bulk to deliver planets wholesale, and have used it to unveil a veritable bonanza of new worlds."

These multiple-planet systems are fertile grounds for studying individual planets and the configuration of planetary neighborhoods. This provides clues to planet formation.

Four of these new planets are less than 2.5 times the size of Earth and orbit in their sun's habitable zone, defined as the range of distance from a star where the surface temperature of an orbiting planet may be suitable for life-giving liquid water.

One of these new habitable zone planets, called Kepler-296f, orbits a star half the size and 5 percent as bright as our sun. Kepler-296f is twice the size of Earth, but scientists do not know whether the planet is a gaseous world, with a thick hydrogen-helium envelope, or it is a water world surrounded by a deep ocean.

"From this study we learn planets in these multi-systems are small and their orbits are flat and circular -- resembling pancakes -- not your classical view of an atom," said Jason Rowe, research scientist at the SETI Institute in Mountain View, Calif., and co-leader of the research. "The more we explore the more we find familiar traces of ourselves amongst the stars that remind us of home."

This latest discovery brings the confirmed count of planets outside our solar system to nearly 1,700. As we continue to reach toward the stars, each discovery brings us one step closer to a more accurate understanding of our place in the galaxy.

Launched in March 2009, Kepler is the first NASA mission to find potentially habitable Earth-size planets. Discoveries include more than 3,600 planet candidates, of which 961 have been verified as bona-fide worlds.

The findings papers will be published March 10 in The Astrophysical Journal.

posted 04-17-2014 01:29 PM

NASA's Kepler telescope discovers first Earth-size planet in 'habitable zone'

Using NASA's Kepler Space Telescope, astronomers have discovered the first Earth-size planet orbiting a star in the "habitable zone" — the range of distance from a star where liquid water might pool on the surface of an orbiting planet. The discovery of Kepler-186f confirms that planets the size of Earth exist in the habitable zone of stars other than our sun.

While planets have previously been found in the habitable zone, they are all at least 40 percent larger in size than Earth and understanding their makeup is challenging. Kepler-186f is more reminiscent of Earth.

"The discovery of Kepler-186f is a significant step toward finding worlds like our planet Earth," said Paul Hertz, NASA's Astrophysics Division director at the agency's headquarters in Washington. "Future NASA missions, like the Transiting Exoplanet Survey Satellite and the James Webb Space Telescope, will discover the nearest rocky exoplanets and determine their composition and atmospheric conditions, continuing humankind's quest to find truly Earth-like worlds."

Although the size of Kepler-186f is known, its mass and composition are not. Previous research, however, suggests that a planet the size of Kepler-186f is likely to be rocky.

"We know of just one planet where life exists — Earth. When we search for life outside our solar system we focus on finding planets with characteristics that mimic that of Earth," said Elisa Quintana, research scientist at the SETI Institute at NASA's Ames Research Center in Moffett Field, Calif., and lead author of the paper published today in the journal Science. "Finding a habitable zone planet comparable to Earth in size is a major step forward."

Kepler-186f resides in the Kepler-186 system, about 500 light-years from Earth in the constellation Cygnus. The system is also home to four companion planets, which orbit a star half the size and mass of our sun. The star is classified as an M dwarf, or red dwarf, a class of stars that makes up 70 percent of the stars in the Milky Way galaxy.

"M dwarfs are the most numerous stars," said Quintana. "The first signs of other life in the galaxy may well come from planets orbiting an M dwarf."

Kepler-186f orbits its star once every 130-days and receives one-third the energy from its star that Earth gets from the sun, placing it nearer the outer edge of the habitable zone. On the surface of Kepler-186f, the brightness of its star at high noon is only as bright as our sun appears to us about an hour before sunset.

"Being in the habitable zone does not mean we know this planet is habitable. The temperature on the planet is strongly dependent on what kind of atmosphere the planet has," said Thomas Barclay, research scientist at the Bay Area Environmental Research Institute at Ames, and co-author of the paper. "Kepler-186f can be thought of as an Earth-cousin rather than an Earth-twin. It has many properties that resemble Earth."

The four companion planets, Kepler-186b, Kepler-186c, Kepler-186d, and Kepler-186e, whiz around their sun every four, seven, 13, and 22 days, respectively, making them too hot for life as we know it. These four inner planets all measure less than 1.5 times the size of Earth.

The next steps in the search for distant life include looking for true Earth-twins — Earth-size planets orbiting within the habitable zone of a sun-like star — and measuring the their chemical compositions. The Kepler Space Telescope, which simultaneously and continuously measured the brightness of more than 150,000 stars, is NASA's first mission capable of detecting Earth-size planets around stars like our sun.

posted 01-06-2015 12:33 PM

Kepler Marks 1,000th Exoplanet and Finds More in Habitable Zone

How many stars like our Sun host planets like our Earth? NASA's Kepler Space Telescope continuously monitored more than 150,000 stars beyond our solar system, and to date has offered scientists an assortment of more than 4,000 candidate planets for further study — the 1,000th of which was recently verified.

Using Kepler data, scientists reached this millenary milestone after validating that eight more candidates spotted by the planet-hunting telescope are, in fact, planets. The Kepler team also has added another 554 candidates to the roll of potential planets, six of which are near-Earth-size and orbit in the habitable zone of stars similar to our Sun.

Three of the newly-validated planets are located in their distant suns' habitable zone, the range of distances from the host star where liquid water might exist on the surface of an orbiting planet. Of the three, two are likely made of rock, like Earth.

"Each result from the planet-hunting Kepler mission's treasure trove of data takes us another step closer to answering the question of whether we are alone in the universe," said John Grunsfeld, associate administrator of NASA's Science Mission Directorate at the agency's headquarters in Washington. "The Kepler team and its science community continue to produce impressive results with the data from this venerable explorer."

To determine whether a planet is made of rock, water or gas, scientists must know its size and mass. When its mass can't be directly determined, scientists can infer what the planet is made of based on its size.

Two of the newly validated planets, Kepler-438b and Kepler-442b, are less than 1.5 times the diameter of Earth. Kepler-438b, 475 light-years away, is 12 percent bigger than Earth and orbits its star once every 35.2 days. Kepler-442b, 1,100 light-years away, is 33 percent bigger than Earth and orbits its star once every 112 days.

Both Kepler-438b and Kepler-442b orbit stars smaller and cooler than our Sun, making the habitable zone closer to their parent star, in the direction of the constellation Lyra. The research paper reporting this finding has been accepted for publication in the Astrophysical Journal.

"With each new discovery of these small, possibly rocky worlds, our confidence strengthens in the determination of the true frequency of planets like Earth," said co-author Doug Caldwell, SETI Institute Kepler scientist at NASA's Ames Research Center at Moffett Field, California. "The day is on the horizon when we'll know how common temperate, rocky planets like Earth are."

With the detection of 554 more planet candidates from Kepler observations conducted May 2009 to April 2013, the Kepler team has raised the candidate count to 4,175. Eight of these new candidates are between one to two times the size of Earth, and orbit in their sun's habitable zone. Of these eight, six orbit stars that are similar to our Sun in size and temperature. All candidates require follow-up observations and analysis to verify they are actual planets.

"Kepler collected data for four years — long enough that we can now tease out the Earth-size candidates in one Earth-year orbits," said Fergal Mullally, SETI Institute Kepler scientist at Ames who led the analysis of a new candidate catalog. "We're closer than we've ever been to finding Earth twins around other Sun-like stars. These are the planets we're looking for."

These findings also have been submitted for publication in the Astrophysical Journal Supplement.

Work is underway to translate these recent discoveries into estimates of how often rocky planets appear in the habitable zones of stars like our Sun, a key step toward NASA's goal of understanding our place in the universe.

Scientists also are working on the next catalog release of Kepler's four-year data set. The analysis will include the final month of data collected by the mission and also will be conducted using sophisticated software that is more sensitive to the tiny telltale signatures of small Earth-size planets than software used in the past.

These results were presented at the 225th meeting of the American Astronomical Society being held in Seattle.

posted 07-23-2015 01:49 PM

NASA's Kepler Mission Discovers Bigger, Older Cousin to Earth

NASA's Kepler mission has confirmed the first near-Earth-size planet in the "habitable zone" around a sun-like star. This discovery and the introduction of 11 other new small habitable zone candidate planets mark another milestone in the journey to finding another "Earth."

The newly discovered Kepler-452b is the smallest planet to date discovered orbiting in the habitable zone — the area around a star where liquid water could pool on the surface of an orbiting planet — of a G2-type star, like our sun. The confirmation of Kepler-452b brings the total number of confirmed planets to 1,030.

"On the 20th anniversary year of the discovery that proved other suns host planets, the Kepler exoplanet explorer has discovered a planet and star which most closely resemble the Earth and our Sun," said John Grunsfeld, associate administrator of NASA's Science Mission Directorate at the agency's headquarters in Washington. "This exciting result brings us one step closer to finding an Earth 2.0."

Kepler-452b is 60 percent larger in diameter than Earth and is considered a super-Earth-size planet. While its mass and composition are not yet determined, previous research suggests that planets the size of Kepler-452b have a good chance of being rocky.

While Kepler-452b is larger than Earth, its 385-day orbit is only 5 percent longer. The planet is 5 percent farther from its parent star Kepler-452 than Earth is from the Sun. Kepler-452 is 6 billion years old, 1.5 billion years older than our sun, has the same temperature, and is 20 percent brighter and has a diameter 10 percent larger.

"We can think of Kepler-452b as an older, bigger cousin to Earth, providing an opportunity to understand and reflect upon Earth's evolving environment," said Jon Jenkins, Kepler data analysis lead at NASA's Ames Research Center in Moffett Field, California, who led the team that discovered Kepler-452b. "It's awe-inspiring to consider that this planet has spent 6 billion years in the habitable zone of its star; longer than Earth. That's substantial opportunity for life to arise, should all the necessary ingredients and conditions for life exist on this planet."

To help confirm the finding and better determine the properties of the Kepler-452 system, the team conducted ground-based observations at the University of Texas at Austin's McDonald Observatory, the Fred Lawrence Whipple Observatory on Mt. Hopkins, Arizona, and the W. M. Keck Observatory atop Mauna Kea in Hawaii. These measurements were key for the researchers to confirm the planetary nature of Kepler-452b, to refine the size and brightness of its host star and to better pin down the size of the planet and its orbit.

The Kepler-452 system is located 1,400 light-years away in the constellation Cygnus. The research paper reporting this finding has been accepted for publication in The Astronomical Journal.

In addition to confirming Kepler-452b, the Kepler team has increased the number of new exoplanet candidates by 521 from their analysis of observations conducted from May 2009 to May 2013, raising the number of planet candidates detected by the Kepler mission to 4,696. Candidates require follow-up observations and analysis to verify they are actual planets.

Above: The artistic concept compares Earth (left) to the new planet, called Kepler-452b, which is about 60 percent larger. The illustration represents one possible appearance for Kepler-452b — scientists do not know whether the planet has oceans and continents like Earth. (NASA/Ames/JPL-Caltech/T. Pyle)

Twelve of the new planet candidates have diameters between one to two times that of Earth, and orbit in their star's habitable zone. Of these, nine orbit stars that are similar to our sun in size and temperature.

"We've been able to fully automate our process of identifying planet candidates, which means we can finally assess every transit signal in the entire Kepler dataset quickly and uniformly," said Jeff Coughlin, Kepler scientist at the SETI Institute in Mountain View, California, who led the analysis of a new candidate catalog. "This gives astronomers a statistically sound population of planet candidates to accurately determine the number of small, possibly rocky planets like Earth in our Milky Way galaxy."

These findings, presented in the seventh Kepler Candidate Catalog, will be submitted for publication in the Astrophysical Journal. These findings are derived from data publically available on the NASA Exoplanet Archive.

Scientists now are producing the last catalog based on the original Kepler mission's four-year data set. The final analysis will be conducted using sophisticated software that is increasingly sensitive to the tiny telltale signatures of Earth-size planets.

posted 04-08-2016 06:10 PM

Kepler spacecraft in emergency mode

During a scheduled contact on Thursday, April 7, mission operations engineers discovered that the Kepler spacecraft was in Emergency Mode (EM). EM is the lowest operational mode and is fuel intensive. Recovering from EM is the team's priority at this time.

The mission has declared a spacecraft emergency, which provides priority access to ground-based communications at the agency's Deep Space Network.

Initial indications are that Kepler entered EM approximately 36 hours ago, before mission operations began the maneuver to orient the spacecraft to point toward the center of the Milky Way for the K2 mission's microlensing observing campaign.

The spacecraft is nearly 75 million miles from Earth, making the communication slow. Even at the speed of light, it takes 13 minutes for a signal to travel to the spacecraft and back.

The last regular contact with the spacecraft was on April 4. The spacecraft was in good health and operating as expected.

Kepler completed its prime mission in 2012, detecting nearly 5,000 exoplanets, of which, more than 1,000 have been confirmed. In 2014 the Kepler spacecraft began a new mission called K2. In this extended mission, K2 continues the search for exoplanets while introducing new research opportunities to study young stars, supernovae, and many other astronomical objects.

Updates will be provided as additional information is available.

posted 04-15-2016 05:58 PM

Kepler Remains Stable as Health Check Continues

Mission manager Charlie Sobeck update

The Kepler spacecraft remains stable as the process of returning it to science continues. The cause of the anomaly, first reported on April 8, remains under investigation.

Since Sunday morning the spacecraft has remained safely "parked" in a stable pointed configuration called Point Rest State. In this state, fuel usage remains low and the communication link to Earth is good. As of Tuesday, mission operations engineers had downlinked all the necessary data from Kepler to triage the situation and plan the steps toward recovery.

The recovery to science began with a thorough assessment of the data, which took a couple days, after which the team had learned all they could about the state of the spacecraft from the data. It was then time to turn back on and test the components deemed low-risk to spacecraft health. Testing begins on the Kepler spacecraft simulator at the flight planning center at Ball Aerospace in Boulder, Colorado. With the ground-based simulation a success, we were ready to conduct the tests on Kepler, 75 million miles away. The engineers sent the instructions, along with commands for the spacecraft to protect itself and enter a safe operating mode if there was a problem, and waited for the spacecraft to report back.

The spacecraft returned a response that is the equivalent of 'so far, so good.' It did not experience any faults from switching on the components, and all the data suggest the components are working normally. The spacecraft is another step closer to returning to scientific observations for the K2 mission.

The photometer — Kepler's camera — and the solid state recorder are powered on. The subsystem interface box, which is the interface between the spacecraft sensors and the main computer, was only briefly powered on for an initial assessment, but should be back online early next week. The team will continue recovering the components, as they are deemed safe and low-risk to the spacecraft.

Over the weekend, NASA's Deep Space Network (DSN) will remain in contact with the spacecraft while the team gets some much-needed rest. To watch the worldwide array of antennas communicate with the spacecraft, tune-in to DSN Now.

The recovery started slowly and carefully, as we initially merely tried to understand the situation and recover the systems least likely to have been the cause. Over the last day and a half, we've begun to turn the corner, by powering on more suspect components. With just one more to go, I expect that we will soon be on the home stretch and picking up speed towards returning to normal science operations.

posted 04-25-2016 07:34 AM

Kepler Recovered and Returned to the K2 Mission

Mission manager Charlie Sobeck update

The Kepler spacecraft has been recovered and, as of 8:30 a.m. PDT April 22, it is back on the job as the K2 mission searching for exoplanets — planets beyond our solar system.

The team began the process of returning the spacecraft to science late on Tuesday (April 19). The process involved a succession of steps over the course of the next two days. The pointing tables and science targets — instructions that tell the spacecraft where to look and at what — were reloaded and confirmed, onboard logs and counters were reset and a new command sequence was created, tested and uploaded to account for the late start of the campaign. The spacecraft is now ready for science operations, officially starting K2's new gravitational microlensing campaign, known as Campaign 9 or C9.

During NASA's Deep Space Network (DSN) contact with the spacecraft yesterday, flight operations engineers at Ball Aerospace and the Laboratory for Atmospheric and Space Physics (LASP) at the University of Colorado, both located in Boulder, turned the spacecraft to point the telescope towards the center of the Milky Way galaxy to start collecting data for C9.

The K2 microlensing team and the ground-based observatories collaborating on C9's global experiment in exoplanet observation are searching through the collected data from the ground telescopes for possible events suitable for observations on larger telescopes, such as the 10-meter telescopes at the W. M. Keck Observatory atop Mauna Kea in Hawaii. During the three-day campaign break, beginning on May 24, data accumulated to that point will be downlinked from the spacecraft to Earth. Shortly thereafter, the scientists will have their first chance to see K2's view of the same events seen on the ground.

The C9 observing period will conclude on July 1, when the galactic center is no longer in view from the vantage point of the spacecraft. K2 will then begin Campaign 10, which will proceed to investigate an entirely new set of interesting astrophysical targets.

Using the DSN, the team will check in on the spacecraft throughout the weekend to ensure it remains stable and continues its task.

To track the contacts with Kepler, tune-in to the DSN Now website. Contacts with the smaller antennas will merely verify that the spacecraft has not gone to Safe or Emergency Mode, while contacts with the larger antennas—indicated as 63, 14 and 43 on the DSN Now—will provide a higher transfer rate to receive health data from the spacecraft.

The cause of the anomaly, first reported on April 8, remains under investigation. The nature of the problem has indications of a transient event, which triggered a barrage of false alarms that eventually overwhelmed the system, placing Kepler in Emergency Mode. Power-cycling the onboard computers and subsystems appears to have cleared the problem. We've returned to science data collection while the investigation proceeds.

The Kepler and K2 missions have been a rewarding job for everyone involved, but there's a special satisfaction to responding well to an emergency like this. The recovery and spacecraft teams at Ball, LASP and NASA's Ames Research Center, had to rely on their own talents and abilities to recover the spacecraft rather than external experts in the short time they had. It is extremely satisfying to see that the challenge was successfully met, and that the team performed in the best traditions of NASA.

posted 05-10-2016 12:15 PM

NASA's Kepler Mission Announces Largest Collection of Planets Ever Discovered

NASA's Kepler mission has verified 1,284 new planets – the single largest finding of planets to date.

"This announcement more than doubles the number of confirmed planets from Kepler," said Ellen Stofan, chief scientist at NASA Headquarters in Washington. "This gives us hope that somewhere out there, around a star much like ours, we can eventually discover another Earth."

Analysis was performed on the Kepler space telescope's July 2015 planet candidate catalog, which identified 4,302 potential planets. For 1,284 of the candidates, the probability of being a planet is greater than 99 percent – the minimum required to earn the status of "planet." An additional 1,327 candidates are more likely than not to be actual planets, but they do not meet the 99 percent threshold and will require additional study. The remaining 707 are more likely to be some other astrophysical phenomena. This analysis also validated 984 candidates previously verified by other techniques.

"Before the Kepler space telescope launched, we did not know whether exoplanets were rare or common in the galaxy. Thanks to Kepler and the research community, we now know there could be more planets than stars," said Paul Hertz, Astrophysics Division director at NASA Headquarters. "This knowledge informs the future missions that are needed to take us ever-closer to finding out whether we are alone in the universe."

Kepler captures the discrete signals of distant planets – decreases in brightness that occur when planets pass in front of, or transit, their stars – much like the May 9 Mercury transit of our sun. Since the discovery of the first planets outside our solar system more than two decades ago, researchers have resorted to a laborious, one-by-one process of verifying suspected planets.

This latest announcement, however, is based on a statistical analysis method that can be applied to many planet candidates simultaneously. Timothy Morton, associate research scholar at Princeton University in New Jersey and lead author of the scientific paper published in The Astrophysical Journal, employed a technique to assign each Kepler candidate a planet-hood probability percentage – the first such automated computation on this scale, as previous statistical techniques focused only on sub-groups within the greater list of planet candidates identified by Kepler.

"Planet candidates can be thought of like bread crumbs," said Morton. "If you drop a few large crumbs on the floor, you can pick them up one by one. But, if you spill a whole bag of tiny crumbs, you're going to need a broom. This statistical analysis is our broom."

In the newly-validated batch of planets, nearly 550 could be rocky planets like Earth, based on their size. Nine of these orbit in their sun's habitable zone, which is the distance from a star where orbiting planets can have surface temperatures that allow liquid water to pool. With the addition of these nine, 21 exoplanets now are known to be members of this exclusive group.

"They say not to count our chickens before they're hatched, but that's exactly what these results allow us to do based on probabilities that each egg (candidate) will hatch into a chick (bona fide planet)," said Natalie Batalha, co-author of the paper and the Kepler mission scientist at NASA's Ames Research Center in Moffett Field, California. "This work will help Kepler reach its full potential by yielding a deeper understanding of the number of stars that harbor potentially habitable, Earth-size planets -- a number that's needed to design future missions to search for habitable environments and living worlds."

Of the nearly 5,000 total planet candidates found to date, more than 3,200 now have been verified, and 2,325 of these were discovered by Kepler. Launched in March 2009, Kepler is the first NASA mission to find potentially habitable Earth-size planets. For four years, Kepler monitored 150,000 stars in a single patch of sky, measuring the tiny, telltale dip in the brightness of a star that can be produced by a transiting planet. In 2018, NASA's Transiting Exoplanet Survey Satellite will use the same method to monitor 200,000 bright nearby stars and search for planets, focusing on Earth and Super-Earth-sized.

posted 06-19-2017 11:31 AM

NASA Releases Kepler Survey Catalog with Hundreds of New Planet Candidates

NASA's Kepler space telescope team has released a mission catalog of planet candidates that introduces 219 new planet candidates, 10 of which are near-Earth size and orbiting in their star's habitable zone, which is the range of distance from a star where liquid water could pool on the surface of a rocky planet.

This is the most comprehensive and detailed catalog release of candidate exoplanets, which are planets outside our solar system, from Kepler's first four years of data. It's also the final catalog from the spacecraft's view of the patch of sky in the Cygnus constellation.

With the release of this catalog, derived from data publically available on the NASA Exoplanet Archive, there are now 4,034 planet candidates identified by Kepler. Of which, 2,335 have been verified as exoplanets. Of roughly 50 near-Earth size habitable zone candidates detected by Kepler, more than 30 have been verified.

Additionally, results using Kepler data suggest two distinct size groupings of small planets. Both results have significant implications for the search for life. The final Kepler catalog will serve as the foundation for more study to determine the prevalence and demographics of planets in the galaxy, while the discovery of the two distinct planetary populations shows that about half the planets we know of in the galaxy either have no surface, or lie beneath a deep, crushing atmosphere – an environment unlikely to host life.

The findings were presented at a news conference Monday at NASA's Ames Research Center in California's Silicon Valley.

"The Kepler data set is unique, as it is the only one containing a population of these near Earth-analogs – planets with roughly the same size and orbit as Earth," said Mario Perez, Kepler program scientist in the Astrophysics Division of NASA's Science Mission Directorate. "Understanding their frequency in the galaxy will help inform the design of future NASA missions to directly image another Earth."

The Kepler space telescope hunts for planets by detecting the miniscule drop in a star's brightness that occurs when a planet crosses in front of it, called a transit.

This is the eighth release of the Kepler candidate catalog, gathered by reprocessing the entire set of data from Kepler's observations during the first four years of its primary mission. This data will enable scientists to determine what planetary populations – from rocky bodies the size of Earth, to gas giants the size of Jupiter – make up the galaxy's planetary demographics.

To ensure a lot of planets weren't missed, the team introduced their own simulated planet transit signals into the data set and determined how many were correctly identified as planets. Then, they added data that appear to come from a planet, but were actually false signals, and checked how often the analysis mistook these for planet candidates. This work told them which types of planets were overcounted and which were undercounted by the Kepler team's data processing methods.

"This carefully-measured catalog is the foundation for directly answering one of astronomy's most compelling questions – how many planets like our Earth are in the galaxy?" said Susan Thompson, Kepler research scientist for the SETI Institute in Mountain View, California, and lead author of the catalog study.

One research group took advantage of the Kepler data to make precise measurements of thousands of planets, revealing two distinct groups of small planets. The team found a clean division in the sizes of rocky, Earth-size planets and gaseous planets smaller than Neptune. Few planets were found between those groupings.

Using the W. M. Keck Observatory in Hawaii, the group measured the sizes of 1,300 stars in the Kepler field of view to determine the radii of 2,000 Kepler planets with exquisite precision.

"We like to think of this study as classifying planets in the same way that biologists identify new species of animals," said Benjamin Fulton, doctoral candidate at the University of Hawaii in Manoa, and lead author of the second study. "Finding two distinct groups of exoplanets is like discovering mammals and lizards make up distinct branches of a family tree."

It seems that nature commonly makes rocky planets up to about 75 percent bigger than Earth. For reasons scientists don't yet understand, about half of those planets take on a small amount of hydrogen and helium that dramatically swells their size, allowing them to "jump the gap" and join the population closer to Neptune's size.

The Kepler spacecraft continues to make observations in new patches of sky in its extended mission, searching for planets and studying a variety of interesting astronomical objects, from distant star clusters to objects such as the TRAPPIST-1 system of seven Earth-size planets, closer to home.

posted 12-14-2017 12:12 PM

Artificial Intelligence, NASA Data Used to Discover Eighth Planet Circling Distant Star

Our solar system now is tied for most number of planets around a single star, with the recent discovery of an eighth planet circling Kepler-90, a Sun-like star 2,545 light years from Earth. The planet was discovered in data from NASA's Kepler Space Telescope.

The newly-discovered Kepler-90i – a sizzling hot, rocky planet that orbits its star once every 14.4 days – was found using machine learning from Google. Machine learning is an approach to artificial intelligence in which computers "learn." In this case, computers learned to identify planets by finding in Kepler data instances where the telescope recorded signals from planets beyond our solar system, known as exoplanets.

"Just as we expected, there are exciting discoveries lurking in our archived Kepler data, waiting for the right tool or technology to unearth them," said Paul Hertz, director of NASA's Astrophysics Division in Washington. "This finding shows that our data will be a treasure trove available to innovative researchers for years to come."

The discovery came about after researchers Christopher Shallue and Andrew Vanderburg and trained a computer to learn how to identify exoplanets in the light readings recorded by Kepler – the miniscule change in brightness captured when a planet passed in front of, or transited, a star. Inspired by the way neurons connect in the human brain, this artificial "neural network" sifted through Kepler data and found weak transit signals from a previously-missed eighth planet orbiting Kepler-90, in the constellation Draco.

While machine learning has previously been used in searches of the Kepler database, this research demonstrates that neural networks are a promising tool in finding some of the weakest signals of distant worlds.

Other planetary systems probably hold more promise for life than Kepler-90. About 30 percent larger than Earth, Kepler-90i is so close to its star that its average surface temperature is believed to exceed 800 degrees Fahrenheit, on par with Mercury. Its outermost planet, Kepler-90h, orbits at a similar distance to its star as Earth does to the Sun.

"The Kepler-90 star system is like a mini version of our solar system. You have small planets inside and big planets outside, but everything is scrunched in much closer," said Vanderburg, a NASA Sagan Postdoctoral Fellow and astronomer at the University of Texas at Austin.

Shallue, a senior software engineer with Google's research team Google AI, came up with the idea to apply a neural network to Kepler data. He became interested in exoplanet discovery after learning that astronomy, like other branches of science, is rapidly being inundated with data as the technology for data collection from space advances.

"In my spare time, I started googling for 'finding exoplanets with large data sets' and found out about the Kepler mission and the huge data set available," said Shallue. "Machine learning really shines in situations where there is so much data that humans can't search it for themselves."

Kepler's four-year dataset consists of 35,000 possible planetary signals. Automated tests, and sometimes human eyes, are used to verify the most promising signals in the data. However, the weakest signals often are missed using these methods. Shallue and Vanderburg thought there could be more interesting exoplanet discoveries faintly lurking in the data.

First, they trained the neural network to identify transiting exoplanets using a set of 15,000 previously-vetted signals from the Kepler exoplanet catalogue. In the test set, the neural network correctly identified true planets and false positives 96 percent of the time. Then, with the neural network having "learned" to detect the pattern of a transiting exoplanet, the researchers directed their model to search for weaker signals in 670 star systems that already had multiple known planets. Their assumption was that multiple-planet systems would be the best places to look for more exoplanets.

"We got lots of false positives of planets, but also potentially more real planets," said Vanderburg. "It's like sifting through rocks to find jewels. If you have a finer sieve then you will catch more rocks but you might catch more jewels, as well."

Kepler-90i wasn't the only jewel this neural network sifted out. In the Kepler-80 system, they found a sixth planet. This one, the Earth-sized Kepler-80g, and four of its neighboring planets form what is called a resonant chain – where planets are locked by their mutual gravity in a rhythmic orbital dance. The result is an extremely stable system, similar to the seven planets in the TRAPPIST-1 system.

Their research paper reporting these findings has been accepted for publication in The Astronomical Journal. Shallue and Vanderburg plan to apply their neural network to Kepler's full set of more than 150,000 stars.

Kepler has produced an unprecedented data set for exoplanet hunting. After gazing at one patch of space for four years, the spacecraft now is operating on an extended mission and switches its field of view every 80 days.

"These results demonstrate the enduring value of Kepler's mission," said Jessie Dotson, Kepler's project scientist at NASA's Ames Research Center in California's Silicon Valley. "New ways of looking at the data – such as this early-stage research to apply machine learning algorithms – promises to continue to yield significant advances in our understanding of planetary systems around other stars. I'm sure there are more firsts in the data waiting for people to find them."

posted 03-14-2018 02:02 PM

NASA's Kepler Spacecraft Nearing the End as Fuel Runs Low

Trailing Earth's orbit at 94 million miles away, the Kepler space telescope has survived many potential knock-outs during its nine years in flight, from mechanical failures to being blasted by cosmic rays. At this rate, the hardy spacecraft may reach its finish line in a manner we will consider a wonderful success. With nary a gas station to be found in deep space, the spacecraft is going to run out of fuel. We expect to reach that moment within several months.

In 2013, Kepler's primary mission ended when a second reaction wheel broke, rendering it unable to hold its gaze steady at the original field of view. The spacecraft was given a new lease on life by using the pressure of sunlight to maintain its pointing, like a kayak steering into the current. Reborn as "K2," this extended mission requires the spacecraft to shift its field of view to new portions of the sky roughly every three months in what we refer to as a "campaign." Initially, the Kepler team estimated that the K2 mission could conduct 10 campaigns with the remaining fuel. It turns out we were overly conservative. The mission has already completed 16 campaigns, and this month entered its 17th.

Our current estimates are that Kepler's tank will run dry within several months – but we've been surprised by its performance before! So, while we anticipate flight operations ending soon, we are prepared to continue as long as the fuel allows.

The Kepler team is planning to collect as much science data as possible in its remaining time and beam it back to Earth before the loss of the fuel-powered thrusters means that we can't aim the spacecraft for data transfer. We even have plans to take some final calibration data with the last bit of fuel, if the opportunity presents itself.

Without a gas gauge, we have been monitoring the spacecraft for warning signs of low fuel— such as a drop in the fuel tank's pressure and changes in the performance of the thrusters. But in the end, we only have an estimate – not precise knowledge. Taking these measurements helps us decide how long we can comfortably keep collecting scientific data.

It's like trying to decide when to gas up your car. Do you stop now? Or try to make it to the next station? In our case, there is no next station, so we want to stop collecting data while we're still comfortable that we can aim the spacecraft to bring it back to Earth. We will continue to provide updates on the science and the spacecraft, which has yet to show warning signs.

Many NASA missions must set a course for a clear-cut ending and reserve enough fuel for one last maneuver. For example, Earth-orbiting spacecraft must avoid collisions with other satellites or an uncontrolled fall to the ground, while planetary missions like Cassini have to reserve fuel to avoid contamination of a potentially life-bearing environment. In Cassini's case, NASA sent the spacecraft into Saturn rather than risk it falling into one of the planet's moons. Deep space missions like Kepler are nowhere near Earth or sensitive environments, which means we can afford to squeeze every last drop of data from the spacecraft — and ultimately that means bringing home even more data for science. Who knows what surprises about our universe will be in that final downlink to Earth?

While Kepler continues to bring us exciting data as it draws close the finish line, the Transiting Exoplanet Survey Satellite (TESS) will be launching on April 16 from Cape Canaveral, Florida. TESS will search nearly the entire sky for planets outside our solar system, focusing on the brightest stars less than 300 light-years away, and adding to Kepler's treasure trove of planet discoveries.

posted 07-14-2018 12:18 PM

NASA's Kepler Spacecraft Pauses Science Observations to Download Science Data

During the week of July 6, NASA’s Kepler team received an indication that the spacecraft fuel tank is running very low. NASA has placed the spacecraft in a hibernation-like state in preparation to download the science data collected in its latest observation campaign. Once the data has been downloaded, the expectation is to start observations for the next campaign with any remaining fuel.

Since May 12, Kepler has been on its 18th observation campaign, staring at a patch of sky towards the constellation of Cancer it previously studied in 2015. The data from this second look will provide astronomers with an opportunity to confirm previous exoplanet candidates and discover new ones. Returning the data back to Earth is the highest priority for the remaining fuel.

To bring the data home, the spacecraft must point its large antenna back to Earth and transmit the data during its allotted Deep Space Network time, which is scheduled in early August. Until then, the spacecraft will remain stable and parked in a no-fuel-use safe mode. On August 2, the team will command the spacecraft to awaken from its no-fuel-use state and maneuver the spacecraft to the correct orientation and downlink the data. If the maneuver and download are successful, the team will begin its 19th observation campaign on August 6 with the remaining fuel.

NASA will provide an update after the scheduled download. The agency has been monitoring the Kepler spacecraft closely for signs of low fuel, and expects it to run out of fuel in the next few months.

As engineers preserve the new data stored on the spacecraft, scientists are continuing to mine existing data already on the ground. Among other findings, recently 24 new planet discoveries were made using data from the 10th observation campaign, adding to the spacecraft’s growing bounty of 2,650 confirmed planets.

posted 08-25-2018 02:38 PM

Aug. 3 — Kepler made contact yesterday and is successfully downloading its store of science data from its last observation campaign, Campaign 18.

Aug. 9 — The Kepler spacecraft has successfully downloaded Campaign 18 data to Earth. We are monitoring the spacecraft very closely and will provide more information when its status has been fully assessed.

Aug. 23 — The Kepler spacecraft went into sleep mode after successfully downloading Campaign 18 data. It is unclear how much fuel is still on board; NASA is looking into the health of the spacecraft and determining a full range of options and next steps.

posted 09-05-2018 03:18 PM

Sept. 5 — The Kepler spacecraft began collecting science data on Aug. 29 for its 19th observation campaign. After being roused from sleep mode the spacecraft's configuration has been modified due to unusual behavior exhibited by one of the thrusters. Preliminary indications are that the telescope's pointing performance may be somewhat degraded. It remains unclear how much fuel remains; NASA continues to monitor the health and performance of the spacecraft.

posted 10-30-2018 03:12 PM

NASA Retires Kepler Space Telescope, Passes Planet-Hunting Torch

After nine years in deep space collecting data that indicate our sky to be filled with billions of hidden planets – more planets even than stars – NASA's Kepler space telescope has run out of fuel needed for further science operations. NASA has decided to retire the spacecraft within its current, safe orbit, away from Earth. Kepler leaves a legacy of more than 2,600 planet discoveries from outside our solar system, many of which could be promising places for life.

Above: This illustration depicts NASA's exoplanet hunter, the Kepler space telescope. The agency announced on Oct. 30, 2018, that Kepler has run out of fuel and is being retired within its current and safe orbit, away from Earth. Kepler leaves a legacy of more than 2,600 exoplanet discoveries. (NASA/Wendy Stenzel/Daniel Rutter)

"As NASA's first planet-hunting mission, Kepler has wildly exceeded all our expectations and paved the way for our exploration and search for life in the solar system and beyond," said Thomas Zurbuchen, associate administrator of NASA's Science Mission Directorate in Washington. "Not only did it show us how many planets could be out there, it sparked an entirely new and robust field of research that has taken the science community by storm. Its discoveries have shed a new light on our place in the universe, and illuminated the tantalizing mysteries and possibilities among the stars."

Kepler has opened our eyes to the diversity of planets that exist in our galaxy. The most recent analysis of Kepler's discoveries concludes that 20 to 50 percent of the stars visible in the night sky are likely to have small, possibly rocky, planets similar in size to Earth, and located within the habitable zone of their parent stars. That means they're located at distances from their parent stars where liquid water – a vital ingredient to life as we know it – might pool on the planet surface.

The most common size of planet Kepler found doesn't exist in our solar system – a world between the size of Earth and Neptune – and we have much to learn about these planets. Kepler also found nature often produces jam-packed planetary systems, in some cases with so many planets orbiting close to their parent stars that our own inner solar system looks sparse by comparison.

"When we started conceiving this mission 35 years ago we didn't know of a single planet outside our solar system," said the Kepler mission's founding principal investigator, William Borucki, now retired from NASA's Ames Research Center in California's Silicon Valley. "Now that we know planets are everywhere, Kepler has set us on a new course that's full of promise for future generations to explore our galaxy."

Launched on March 6, 2009, the Kepler space telescope combined cutting-edge techniques in measuring stellar brightness with the largest digital camera outfitted for outer space observations at that time. Originally positioned to stare continuously at 150,000 stars in one star-studded patch of the sky in the constellation Cygnus, Kepler took the first survey of planets in our galaxy and became the agency's first mission to detect Earth-size planets in the habitable zones of their stars.

"The Kepler mission was based on a very innovative design. It was an extremely clever approach to doing this kind of science," said Leslie Livesay, director for astronomy and physics at NASA's Jet Propulsion Laboratory, who served as Kepler project manager during mission development. "There were definitely challenges, but Kepler had an extremely talented team of scientists and engineers who overcame them."

Four years into the mission, after the primary mission objectives had been met, mechanical failures temporarily halted observations. The mission team was able to devise a fix, switching the spacecraft's field of view roughly every three months. This enabled an extended mission for the spacecraft, dubbed K2, which lasted as long as the first mission and bumped Kepler's count of surveyed stars up to more than 500,000.

The observation of so many stars has allowed scientists to better understand stellar behaviors and properties, which is critical information in studying the planets that orbit them. New research into stars with Kepler data also is furthering other areas of astronomy, such as the history of our Milky Way galaxy and the beginning stages of exploding stars called supernovae that are used to study how fast the universe is expanding. The data from the extended mission were also made available to the public and science community immediately, allowing discoveries to be made at an incredible pace and setting a high bar for other missions. Scientists are expected to spend a decade or more in search of new discoveries in the treasure trove of data Kepler provided.

"We know the spacecraft's retirement isn't the end of Kepler's discoveries," said Jessie Dotson, Kepler's project scientist at NASA's Ames Research Center in California's Silicon Valley. "I'm excited about the diverse discoveries that are yet to come from our data and how future missions will build upon Kepler's results."

Before retiring the spacecraft, scientists pushed Kepler to its full potential, successfully completing multiple observation campaigns and downloading valuable science data even after initial warnings of low fuel. The latest data, from Campaign 19, will complement the data from NASA's newest planet hunter, the Transiting Exoplanet Survey Satellite, launched in April. TESS builds on Kepler's foundation with fresh batches of data in its search of planets orbiting some 200,000 of the brightest and nearest stars to the Earth, worlds that can later be explored for signs of life by missions, such as NASA's James Webb Space Telescope.

NASA's Ames Research Center in California's Silicon Valley manages the Kepler and K2 missions for NASA's Science Mission Directorate. NASA's Jet Propulsion Laboratory in Pasadena, California, managed Kepler mission development. Ball Aerospace & Technologies Corporation in Boulder, Colorado, operates the flight system with support from the Laboratory for Atmospheric and Space Physics at the University of Colorado in Boulder.

posted 04-15-2020 12:13 PM

Earth-Size, Habitable Zone Planet Found Hidden in Early NASA Kepler Data

A team of transatlantic scientists, using reanalyzed data from NASA's Kepler space telescope, has discovered an Earth-size exoplanet orbiting in its star's habitable zone, the area around a star where a rocky planet could support liquid water.

Above: An illustration of Kepler-1649c orbiting around its host red dwarf star. This newly discovered exoplanet is in its star's habitable zone and is the closest to Earth in size and temperature found yet in Kepler's data. (NASA/Ames Research Center/Daniel Rutter)

Scientists discovered this planet, called Kepler-1649c, when looking through old observations from Kepler, which the agency retired in 2018. While previous searches with a computer algorithm misidentified it, researchers reviewing Kepler data took a second look at the signature and recognized it as a planet. Out of all the exoplanets found by Kepler, this distant world – located 300 light-years from Earth – is most similar to Earth in size and estimated temperature.

This newly revealed world is only 1.06 times larger than our own planet. Also, the amount of starlight it receives from its host star is 75% of the amount of light Earth receives from our Sun – meaning the exoplanet's temperature may be similar to our planet's, as well. But unlike Earth, it orbits a red dwarf. Though none have been observed in this system, this type of star is known for stellar flare-ups that may make a planet's environment challenging for any potential life.

"This intriguing, distant world gives us even greater hope that a second Earth lies among the stars, waiting to be found," said Thomas Zurbuchen, associate administrator of NASA's Science Mission Directorate in Washington. "The data gathered by missions like Kepler and our Transiting Exoplanet Survey Satellite (TESS) will continue to yield amazing discoveries as the science community refines its abilities to look for promising planets year after year."

There is still much that is unknown about Kepler-1649c, including its atmosphere, which could affect the planet's temperature. Current calculations of the planet's size have significant margins of error, as do all values in astronomy when studying objects so far away. But based on what is known, Kepler-1649c is especially intriguing for scientists looking for worlds with potentially habitable conditions.

Above: A comparison of Earth and Kepler-1649c, an exoplanet only 1.06 times Earth's radius. (NASA/Ames Research Center/Daniel Rutter)

There are other exoplanets estimated to be closer to Earth in size, such as TRAPPIST-1f and, by some calculations, Teegarden c. Others may be closer to Earth in temperature, such as TRAPPIST-1d and TOI 700d. But there is no other exoplanet that is considered to be closer to Earth in both of these values that also lies in the habitable zone of its system.

"Out of all the mislabeled planets we've recovered, this one's particularly exciting – not just because it's in the habitable zone and Earth-size, but because of how it might interact with this neighboring planet," said Andrew Vanderburg, a researcher at the University of Texas at Austin and first author on the paper released today (April 15) in The Astrophysical Journal Letters. "If we hadn't looked over the algorithm's work by hand, we would have missed it."

Kepler-1649c orbits its small red dwarf star so closely that a year on Kepler-1649c is equivalent to only 19.5 Earth days. The system has another rocky planet of about the same size, but it orbits the star at about half the distance of Kepler-1649c, similar to how Venus orbits our Sun at about half the distance that Earth does. Red dwarf stars are among the most common in the galaxy, meaning planets like this one could be more common than we previously thought.

Looking for False Positives

Previously, scientists on the Kepler mission developed an algorithm called Robovetter to help sort through the massive amounts of data produced by the Kepler spacecraft, managed by NASA's Ames Research Center in California's Silicon Valley. Kepler searched for planets using the transit method, staring at stars, looking for dips in brightness as planets passed in front of their host stars.

Most of the time, those dips come from phenomena other than planets – ranging from natural changes in a star's brightness to other cosmic objects passing by – making it look like a planet is there when it's not. Robovetter's job was to distinguish the 12% of dips that were real planets. Those signatures Robovetter determined to be from other sources were labeled "false positives," the term for a test result mistakenly classified as positive.

With an enormous number of tricky signals, astronomers knew the algorithm would make mistakes and would need to be double-checked – a perfect job for the Kepler False Positive Working Group. That team reviews Robovetter's work, going through all false positives to ensure they are truly errors and not exoplanets, ensuring fewer potential discoveries are overlooked. As it turns out, Robovetter had mislabeled Kepler-1649c.

Even as scientists work to further automate analysis processes to get the most science as possible out of any given dataset, this discovery shows the value of double-checking automated work. Even six years after Kepler stopped collecting data from the original Kepler field – a patch of sky it stared at from 2009 to 2013, before going on to study many more regions – this rigorous analysis uncovered one of the most unique Earth-analogs discovered yet.

A Possible Third Planet

Kepler-1649c not only is one of the best matches to Earth in terms of size and energy received from its star, but it provides an entirely new look at its home system. For every nine times the outer planet in the system orbits the host star, the inner planet orbits almost exactly four times. The fact that their orbits match up in such a stable ratio indicates the system itself is extremely stable, and likely to survive for a long time.

Nearly perfect period ratios are often caused by a phenomenon called orbital resonance, but a nine-to-four ratio is relatively unique among planetary systems. Usually resonances take the form of ratios such as two-to-one or three-to-two. Though unconfirmed, the rarity of this ratio could hint to the presence of a middle planet with which both the inner and outer planets revolve in synchronicity, creating a pair of three-to-two resonances.

Above: An illustration of what Kepler-1649c could look like from its surface. (NASA/Ames Research Center/Daniel Rutter)

The team looked for evidence of such a mystery third planet, with no results. However, that could be because the planet is too small to see or at an orbital tilt that makes it impossible to find using Kepler's transit method.

Either way, this system provides yet another example of an Earth-size planet in the habitable zone of a red dwarf star. These small and dim stars require planets to orbit extremely close to be within that zone – not too warm and not too cold – for life as we know it to potentially exist. Though this single example is only one among many, there is increasing evidence that such planets are common around red dwarfs.

"The more data we get, the more signs we see pointing to the notion that potentially habitable and Earth-size exoplanets are common around these kinds of stars," said Vanderburg. "With red dwarfs almost everywhere around our galaxy, and these small, potentially habitable and rocky planets around them, the chance one of them isn't too different than our Earth looks a bit brighter."
